System And Components
142-1756 LINES GP-FUELS/N 7MZ1-UP
Group No: 142-1756
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 5G7817 | 2 BOSS (11X25X18-MM THK) | 1 | |
| 1716729 | 3 VALVE GP-SHUTOFF (MANUAL) | 2 | |
| 8T0131 | 4 ELBOW | 2 | |
| 1310463 | 5 FILTER GP-WATER SEP & FUEL | 1 | |
| 1375541 | 6 PUMP GP-FUEL PRIMING | 1 | |
| 1418368 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1544493 | 8 HOSE AS | 1 | |
| 1544495 | 9 TUBE AS | 1 | |
| 1544496 | 10 TUBE AS | 1 | |
| 1546628 | 11 HOSE AS | 1 | |
| 2372857 | 12 HOSE AS | 1 | |
| 1618678 | 13 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 1721533 | 14 HOSE AS | 1 | |
| 2006153 | 15 HOSE AS | 1 | |
| 6D4636 | 16 CLIP (LOOP) | 2 | |
| 1753183 | 17 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1488340 | 18 CONNECTOR AS | 2 | |
| 6V8639 | CONNECTOR | 2 | |
| 3K0360 | SEAL-O-RING | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1488365 | 19 ELBOW AS | 3 | |
| 8T6876 | ELBOW | 2 | |
| 3J1907 | SEAL-O-RING | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1488380 | 20 ELBOW AS | 2 | |
| 6V8988 | ELBOW | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1488390 | 21 ELBOW AS | 1 | |
| 6V8626 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1645624 | 22 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 9X2085 | ELBOW | 1 | |
| 1504048 | 23 ELBOW AS | 1 | |
| 6V8722 | ELBOW | 2 | |
| 3K0360 | SEAL-O-RING | 2 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1B3057 | 24 CLIP | 2 | |
| 3G8054 | 25 CLIP (TAB) | 1 | |
| 3G8057 | 26 CLIP (SLOT) | 1 | |
| 1615104 | 27 GUARD | 1 | |
| 3S8665 | 28 CLIP (LOOP) | 5 | |
| 5M3062 | 29 BOLT (3/8-16X0.75-IN) | 1 | |
| 6D4244 | 30 CLIP (LOOP) | 3 | |
| 6D4247 | 31 CLIP | 7 | |
| 8T4224 | 32 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 6V0974 | 33 GROMMET | 1 | |
| 6V8732 | 34 UNION | 1 | |
| 6V8918 | 35 BOLT (5/16-18X1.25-IN) | 1 | |
| 6V9169 | 36 NUT (13/16-16-THD) | 2 | |
| 7J9108 | 37 SEAL-O-RING | 4 | |
| 7X2501 | 38 BOLT (1/4-20X1.25-IN) | 1 | |
| 8T4121 | 39 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4136 | 40 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4137 | 41 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4183 | 42 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4186 | 43 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4195 | 44 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4205 | 45 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 8T4223 | 46 WASHER-HARD (13.5X25.5X3-MM THK) | 4 |
