System And Components
183-2817 LINES GP-WATERS/N BCK1-289
Group No: 183-2817
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P4616 | 1 COUPLING | 2 | |
| 7E1456 | 2 CONNECTOR | 2 | |
| 7E1459 | 3 HOSE AS | 1 | |
| 9R5008 | 4 SPACER (11X20X6-MM THK) | 2 | |
| 0059702 | 5 TEE-UNION | 1 | |
| 1499264 | 6 TUBE AS | 1 | |
| 1499265 | 7 TUBE AS | 2 | |
| 1499266 | 8 TUBE AS | 1 | |
| 1499267 | 9 TUBE AS | 1 | |
| 1499268 | 10 BRACKET | 2 | |
| 0307951 | 11 ELBOW-FLARED | 2 | |
| 0308310 | 12 CONNECTOR | 1 | |
| 0L1143 | 13 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L2070 | 14 BOLT (3/8-16X2.25-IN) | 4 | |
| 4B3388 | 15 BOLT (5/16-18X1.125-IN) | 2 | |
| 4P3563 | 16 CLAMP AS | 12 | |
| 1081434 | GROMMET | 1 | |
| 5P3165 | 17 TEE-SWIVEL | 1 | |
| 5P7701 | 18 SEAL-O-RING | 2 | |
| 6V1903 | 19 SEAL-O-RING | 8 | |
| 7L4773 | 20 SEAL-O-RING | 2 | |
| 8M0744 | 21 NUT-FLARED (1-1/16-12-THD) | 1 | |
| 8M0745 | 22 REDUCER-FLARED | 1 | |
| 9L9132 | 23 WASHER-HARD (10.2X25.5X2.5-MM THK) | 8 | |
| 9N0869 | 24 WASHER-HARD (8.8X25.5X2-MM THK) | 2 | |
| 9S4188 | 25 PLUG | 4 | |
| 9S7739 | 26 UNION-FLARED | 1 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 2 |
