System And Components
253-7179 RADIATOR GPPART OF 467-0263 ENGINE AR-COMPLETE
Group No: 253-7179 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6L8617 | 1 CAP-PRESSURE (7-PSI)(RADIATOR) | 1 | |
| 3160488 | 2 SPACER (11X25X78-MM THK) | 2 | |
| 8T4983 | 3 CLAMP-HOSE | 2 | |
| 2284302 | 4 RADIATOR GP | 1 | |
| 2284306 | 5 GUARD AS-FAN | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 2284308 | 6 SUPPORT AS | 1 | |
| 2284309 | 7 SUPPORT AS | 1 | |
| 2284310 | 8 BRACE | 2 | |
| 2284337 | 9 BRACKET AS | 1 | |
| 2330074 | 10 BRACKET | 1 | |
| 1124159 | 11 MOUNTING AS | 2 | |
| 1184977 | 12 BOLT (M16X2X65-MM) | 2 | |
| 1877331 | 13 MOUNT-RUBBER | 4 | |
| 2N1117 | 14 CLIP | 1 | |
| 2S2053 | 15 CLIP (LOOP) | 2 | |
| 7G8839 | 16 SPACER (13.5X57X6-MM THK) | 4 | |
| 7X0607 | 17 WASHER-HARD (20X55X8-MM THK) | 2 | |
| 7X2575 | 18 BOLT (M24X3X60-MM) | 8 | |
| 7X3392 | 19 WASHER-HARD (13.5X22.5X3-MM THK) | 4 | |
| 8T4001 | 20 NUT (M24X3-THD) | 8 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4133 | 22 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 23 BOLT (M10X1.5X25-MM) | 16 | |
| 8T4137 | 24 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4139 | 25 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4167 | 26 WASHER-HARD (26X44X4-MM THK) | 16 | |
| 8T4176 | 27 BOLT (M12X1.75X90-MM) | 2 | |
| 8T4195 | 28 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4244 | 30 NUT (M12X1.75-THD) | 2 | |
| 8T6685 | 31 BOLT (M10X1.5X110-MM) | 2 | |
| 8T6765 | 32 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9X8257 | 33 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 5P5991 | 34 HOSE (0.3-M) | ||
| 5P1251 | 35 HOSE (138-CM) | ||
| 7X7729 | 36 WASHER (11X25X3-MM THK) | 14 |
