System And Components
386-4926 HOOD GP-ENGINES/N L4E2986-UP
Group No: 386-4926
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T8737 | 1 PLUG-SEAL | 2 | |
| 2743782 | 2 CAP-SEAL | 1 | |
| 3283984 | 3 WIRING GP-LIGHTING | 1 | |
| 3323816 | 4 GRILL AS (LH) | 1 | |
| 3323817 | 5 GRILL AS (RH) | 1 | |
| 3323818 | 6 HINGE AS (LH) | 1 | |
| 5G8871 | BOSS (M6X1-THD) | 1 | |
| 7T1099 | LINK | 1 | |
| 3323819 | 7 HINGE AS (RH) | 1 | |
| 5G8871 | BOSS (M6X1-THD) | 1 | |
| 7T1099 | LINK | 3 | |
| 3323830 | 8 GRILL AS | 1 | |
| 3581460 | 9 INSULATION | 1 | |
| 3581461 | 10 INSULATION | 1 | |
| 3581462 | 11 INSULATION | 1 | |
| 3581463 | 12 INSULATION | 1 | |
| 3581464 | 13 INSULATION | 1 | |
| 3595892 | 14 HINGE AS | 2 | |
| 5G8871 | BOSS (M6X1-THD) | 1 | |
| 7T1099 | LINK | 1 | |
| 3595895 | 15 HINGE AS | 2 | |
| 3596322 | 16 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 3596325 | 17 BRACKET AS | 1 | |
| 3633870 | 18 BRACKET AS | 1 | |
| 3633871 | 19 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 3638613 | 20 FENDER GP (FRONT) | 1 | |
| 3662298 | 21 HOOD AS | 1 | |
| 8T4121 | WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4136 | BOLT (M10X1.5X25-MM) | 14 | |
| 7T1099 | LINK | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 16 | |
| 3722830 | 22 BRACKET AS | 1 | |
| 3750094 | 23 SEAL AS (LH) | 1 | |
| 3750095 | 24 SEAL AS (RH) | 1 | |
| 3807951 | 25 BRACKET AS | 1 | |
| 3845268 | 26 PANEL AS (LH) | 1 | |
| 3845269 | 27 PANEL AS (RH) | 1 | |
| 4165840 | 34 BUSHING-FLANGE | 2 | |
| 4375176 | 35 PANEL AS (GRILL) | 1 | |
| 4601110 | 36 PIN-GUIDE | 2 | |
| 1779645 | 37 KIT-RECEPTACLE (2-PIN) | 1 | |
| 2167352 | 38 SCREW-TRUSS HEAD (M8X1.25X30-MM) | 4 | |
| 2451094 | 39 NUT-RETAINING | 4 | |
| 3E8020 | 40 SCREW-TRUSS HEAD (M6X1X25-MM) | 8 | |
| 3T0852 | 41 LOCKNUT (M8X1.25-THD) | 6 | |
| 5P1076 | 42 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P4116 | 43 WASHER-HARD (8.8X20.5X2-MM THK) | 17 | |
| 8T4121 | 44 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4183 | 45 BOLT (M12X1.75X40-MM) | 6 | |
| 8T4186 | 46 BOLT (M10X1.5X40-MM) | 6 | |
| 8T4189 | 47 BOLT (M8X1.25X20-MM) | 14 | |
| 8T4195 | 48 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4224 | 49 WASHER-HARD (8.8X16X2-MM THK) | 26 | |
| 8T4908 | 50 BOLT (M8X1.25X25-MM) | 11 | |
| 8T7547 | 51 BOLT (M8X1.25X30-MM) | 8 | |
| 9X2038 | 52 WASHER (7X19X2-MM THK) | 8 | |
| 2228450 | 53 SEAL (89-CM) | ||
| 4171541 | 54 SEAL (220-CM) | ||
| 3944883 | 55 INSULATION | 1 | |
| 3944886 | 56 INSULATION | 1 | |
| 3944887 | 57 INSULATION | 1 | |
| 3944888 | 58 INSULATION | 1 | |
| 3944889 | 59 INSULATION | 1 | |
| 3944890 | 60 INSULATION | 1 |
