System And Components
430-4374 LINES GP-PUMP -IMPLEMENTS/N GTL1-UP
Group No: 430-4374
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 9U6995 | 2 FITTING GP-HYDRAULIC (CLEAN GAS INDUCTION) | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 0342151 | CONNECTOR | 1 | |
| 1503024 | 3 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P4924 | ELBOW | 1 | |
| 2042281 | 4 STRAP-CABLE | 3 | |
| 2376094 | 5 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 2376095 | CONNECTOR | 1 | |
| 2381844 | 6 ELBOW | 1 | |
| 2644297 | 7 SENSOR AS-TEMPERATURE (2-PIN)(WATER, COOLANT) | 1 | |
| 1376645 | PAD-CONNECTOR | 1 | |
| 2681517 | 8 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1498142 | CONNECTOR | 1 | |
| 3233308 | 9 CAP | 4 | |
| 3295510 | 10 CONNECTOR AS | 1 | |
| 8T0198 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3453753 | 11 MOUNTING-CABLE TIE | 1 | |
| 3456479 | 12 HOSE AS | 1 | |
| 3737039 | 13 VALVE GP-CHECK (PUMP CASE DRAIN) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 4210260 | 14 TEE | 1 | |
| 4223137 | 15 BRACKET AS | 1 | |
| 4223375 | 16 HOSE AS | 1 | |
| 4229407 | 17 ADAPTER AS | 1 | |
| 4223149 | SEAL-O-RING | 1 | |
| 4304423 | 18 HOSE | 1 | |
| 5216101 | 19 CLAMP | 4 | |
| 4358878 | 20 HOSE | 1 | |
| 4488749 | 21 HOSE AS | 1 | |
| 4775069 | 22 TUBE AS | 1 | |
| 4805507 | 23 HOSE AS | 1 | |
| 1106349 | 24 FITTING AS (QUICK DISCONNECT) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1420038 | 25 ELBOW | 1 | |
| 1488336 | 26 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488357 | 27 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488361 | 28 ELBOW AS (90-DEG) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9200 | ELBOW | 1 | |
| 1488371 | 29 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 1488378 | 30 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488411 | 31 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1645567 | 32 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1783620 | 33 STRAP-DUAL CLAMP | 2 | |
| 2048000 | 34 MOUNTING-CABLE TIE | 1 | |
| 2663314 | 35 BOLT-FLANGE HEAD (M6X1X20.5-MM) | 1 | |
| 3436821 | 36 CLAMP-BAND | 2 | |
| 3474163 | 37 CLAMP-BAND | 2 | |
| 5216102 | 38 CLAMP | 2 | |
| 5216104 | 39 CLAMP | 2 | |
| 5216105 | 40 CLAMP | 2 | |
| 3K0360 | 41 SEAL-O-RING | 1 | |
| 4B9302 | 42 CLIP (LOOP) | 1 | |
| 5K9090 | 43 SEAL-O-RING | 1 | |
| 6V0852 | 44 CAP-DUST | 3 | |
| 6V8397 | 45 SEAL-O-RING | 1 | |
| 8T4121 | 46 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4136 | 47 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4223 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4956 | 49 BOLT (M12X1.75X35-MM) | 4 | |
| 4231984 | 50 HOSE (17.7-IN) | ||
| 4231982 | 51 HOSE (19.7-IN) | ||
| 4231982 | 51A HOSE (3.6-IN) | ||
| 4231985 | 52 HOSE (36.2-IN) | ||
| 5P4115 | 53 WASHER-HARD (7.2X19X2-MM THK) | 1 |
