Assembly
100%

291-1446 LINES GP-FUEL INJECTIONS/N R1A1885-UP

Group No: 291-1446
Part NumberPart NameQty
4P06921 CLAMP AS4
1081434GROMMET1
4P06932 CLAMP AS8
1081434GROMMET2
5G54323 SPACER (10.5X16X18-MM THK)1
6B62054 SPACER (0.438X0.875X1.281-IN THK)2
6V43635 ELBOW (90-DEG)1
7C76826 ADAPTER-FUEL MANIFOLD (RH)1
7C76837 ADAPTER-FUEL MANIFOLD (LH)1
7N68068 SEAL-RECTANGULAR4
44890179 ADAPTER AS24
2147568SEAL-O-RING1
2287089SEAL-O-RING1
4489016ADAPTER1
9N405310 SPRING1
030797711 ELBOW (90-DEG)1
114547712 PLUNGER-VALVE1
116325913 BRACKET1
450722714 TUBE AS-FUEL12
450722615 TUBE AS-FUEL12
450796916 MANIFOLD GP-FUEL (RH)1
450797017 MANIFOLD GP-FUEL (LH)1
185704218 TUBE AS1
185704319 TUBE AS1
386622920 ELBOW AS4
2385081SEAL-O-RING1
2501497ELBOW1
260915221 VALVE-CHECK (FUEL)1
274985522 BRACKET1
286064623 TUBE AS1
286064824 TUBE AS1
286064925 TUBE AS1
291144726 TUBE AS1
003858127 TEE-UNION1
0L114328 BOLT (3/8-16X2.5-IN)1
0L135229 BOLT (3/8-16X3.25-IN)2
0L207030 BOLT (3/8-16X2.25-IN)1
0T006531 BOLT (3/8-16X3.5-IN)2
1D453932 BOLT (5/16-18X2.5-IN)1
2P763633 CONNECTOR (3/4-16 STR-THD)2
214756834 SEAL-O-RING1
214756635 SEAL-O-RING1
238508036 SEAL-O-RING2
1D454137 BOLT (5/16-18X3-IN)1
5M289438 WASHER-HARD (10.2X18.5X2.5-MM THK)8
5S000339 NUT (5/16-18-THD)1
6V436240 CONNECTOR1
238508141 SEAL-O-RING5
7K337742 PIPE1
9M197443 WASHER-HARD (8.8X16X2-MM THK)3
9M458444 CONNECTOR2
9S418245 PLUG (7/16-20-THD)1
9S875246 NUT-FULL (3/8-16-THD)2
228708947 SEAL-O-RING24
