System And Components
432-4976 AIR COMPRESSOR GPPART OF 475-8294 ENGINE AR-PRIMARY
Group No: 432-4976
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1022073 | 1 SEAL-O-RING | 1 | |
| 1134608 | 2 ADAPTER | 1 | |
| 1138076 | 3 PIN | 1 | |
| 1263219 | 4 SEAL-O-RING | 1 | |
| 1988262 | 5 COVER AS | 1 | |
| 1988263 | SEAL-O-RING | 1 | |
| 2143203 | 6 WASHER (SEALING) | 1 | |
| 2474928 | 7 WASHER (16.5X20.5X1.6-MM THK) | 2 | |
| 2592611 | 8 HOSE | 1 | |
| 2592612 | 9 HOSE | 1 | |
| 2592614 | 10 BRACKET | 1 | |
| 2592623 | 11 GEAR (34-TEETH) | 1 | |
| 2733691 | 12 BOLT (M8X1.25X80-MM) | 4 | |
| 2931875 | 13 BOLT (M10X1.5X16-MM) | 2 | |
| 3961190 | 14 CLIP-HOSE | 4 | |
| 4511179 | 15 COMPRESSOR | 1 | |
| 1840983 | 16 NUT-HEX FLANGE (M12X1.75-THD) | 2 | |
| 6I0260 | 17 BOLT (M8X1.25X25-MM) | 4 | |
| 0358017 | 18 UNION | 1 | |
| 2096825 | 19 ADAPTER | 2 | |
| 2592613 | 20 TUBE AS | 1 | |
| 0676265 | FITTING-BRASS | 2 | |
| 3653308 | NUT-COMPRESSION (3/8-24-THD) | 2 | |
| 2931877 | 21 ADAPTER GP-AIR COMPRESSOR | 1 |
