System And Components
294-3679 LADDER & WALKWAY GPS/N 6HK1-UP
Group No: 294-3679
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A7321 | 1 BOX AS | 1 | |
| 8F8551 | HINGE-BUTT | 1 | |
| 4V0661 | 2 MOUNT | 2 | |
| 6B8085 | 3 SNAP-CHAIN | 1 | |
| 8X9874 | 4 CHAIN | 1 | |
| 1153580 | 5 PLATE | 6 | |
| 1179079 | 6 PLATE AS | 1 | |
| 1180429 | 7 PLATE AS | 1 | |
| 1680391 | 8 PLATE | 2 | |
| 2854166 | 9 PLATE AS | 1 | |
| 2854168 | 10 PLATE AS | 1 | |
| 2854171 | 11 BRACKET AS | 2 | |
| 2854206 | 12 PLATFORM AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 10 | |
| 2854271 | 13 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 12 | |
| 2854272 | 14 PLATE | 2 | |
| 2854273 | 15 GUARD AS | 1 | |
| 2854274 | 16 GUARD | 1 | |
| 2854275 | 17 GUARD AS | 1 | |
| 2854329 | 18 BRACKET AS | 2 | |
| 5P0765 | 19 HOSE (58-CM) | ||
| 2943680 | 20 BUMPER AS | 1 | |
| 2943681 | 21 STEP GP | 2 | |
| 2943682 | 22 BRACKET AS | 1 | |
| 2943684 | 23 LADDER AS | 1 | |
| 2943685 | 24 LADDER AS | 1 | |
| 2943689 | 25 WALKWAY AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 8 | |
| 2943692 | 26 PANEL AS | 1 | |
| 2943693 | 27 PANEL AS | 1 | |
| 2943694 | 28 DEFLECTOR-MUD | 2 | |
| 2943695 | 29 PLATE | 2 | |
| 2943696 | 30 PLATE | 2 | |
| 2943697 | 31 PLATE | 2 | |
| 2943706 | 32 PLATE | 1 | |
| 2956359 | 33 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 2956360 | 34 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3003966 | 35 WIRING GP-LIGHTING | 1 | |
| 3113248 | 36 WALKWAY AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 8 | |
| 3113251 | 37 HANDRAIL GP | 1 | |
| 3296142 | 38 PLATE | 1 | |
| 0089792 | 39 SCREW-WASHER HEAD (1/4-20X0.5-IN) | 4 | |
| 0S1587 | 40 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1620 | 41 BOLT (1/2-13X0.75-IN) | 13 | |
| 1A5822 | 42 BOLT (1/2-13X2.75-IN) | 2 | |
| 1F7958 | 43 NUT-FULL (1/2-13-THD) | 2 | |
| 1K6872 | 44 LOCKNUT (1/2-13-THD) | 2 | |
| 2S1654 | 45 WASHER (3.5X44.5X6-MM THK) | 2 | |
| 3Y7829 | 46 BOSS (3/8-16-THD) | 5 | |
| 4L6454 | 47 BOLT (3/8-16X1-IN) | 51 | |
| 5C2890 | 48 NUT (M6X1-THD) | 4 | |
| 5P1075 | 49 WASHER-HARD (10.2X22.5X3-MM THK) | 52 | |
| 5P1076 | 50 WASHER-HARD (13.5X30X4-MM THK) | 73 | |
| 5P2228 | 51 BOLT (1/2-13X1-IN) | 11 | |
| 5P2566 | 52 BOLT (1/2-13X1.5-IN) | 6 | |
| 5P7468 | 53 CLIP (SLOT) | 12 | |
| 5P7469 | 54 CLIP (TAB) | 12 | |
| 5P8245 | 55 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 6V7687 | 56 LOCKNUT (M12X1.75-THD) | 4 | |
| 6V8188 | 57 NUT (1/2-13-THD) | 2 | |
| 6V8801 | 58 NUT (3/8-16-THD) | 16 | |
| 7G8839 | 59 SPACER (13.5X57X6-MM THK) | 6 | |
| 7T1099 | 60 LINK | 1 | |
| 7T8331 | 61 MOUNT AS | 6 | |
| 7X0325 | 62 BOLT (1/2-13X2.5-IN) | 2 | |
| 8C4436 | 63 BOLT (1/2-13X1.375-IN) | 4 | |
| 8C8451 | 64 BOLT (M6X1X40-MM) | 1 | |
| 8T2502 | 65 BOLT (3/8-16X1.125-IN) | 18 | |
| 8T3597 | 66 NUT-WELD (M12X1.75-THD) | 5 | |
| 8T4121 | 67 WASHER-HARD (11X21X2.5-MM THK) | 48 | |
| 8T4137 | 68 BOLT (M10X1.5X20-MM) | 36 | |
| 8T4139 | 69 BOLT (M12X1.75X30-MM) | 17 | |
| 8T4183 | 70 BOLT (M12X1.75X40-MM) | 12 | |
| 8T4195 | 71 BOLT (M10X1.5X30-MM) | 12 | |
| 8T4205 | 72 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 8T4222 | 73 WASHER-PLATED (11X32X2.5-MM THK) | 4 | |
| 8T4223 | 74 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4244 | 75 NUT (M12X1.75-THD) | 12 | |
| 8T4648 | 76 BOLT (M12X1.75X70-MM) | 4 | |
| 8T4896 | 77 WASHER-HARD (10.2X18.5X2.5-MM THK) | 48 | |
| 8T4910 | 78 BOLT (M12X1.75X60-MM) | 3 | |
| 8T7087 | 79 GROMMET (34-MM ID) | 12 | |
| 8T8917 | 80 BOLT (1/2-13X1.25-IN) | 4 | |
| 8W7381 | 81 BLOCK | 5 | |
| 8X4903 | 82 BLOCK | 2 | |
| 9B7237 | 83 BOLT (3/8-16X1.25-IN) | 19 |
