System And Components
423-1695 LADDER GP -EXTRA QUIETS/N APX1-UP
Group No: 423-1695
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4V0661 | 1 MOUNT | 2 | |
| 4V9804 | 2 PLATE | 12 | |
| 4V9810 | 3 STEP AS | 6 | |
| 5T8066 | 4 BRACE | 1 | |
| 5T8217 | 5 PLATE | 1 | |
| 5T8218 | 6 PLATE AS | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 3 | |
| 5T8220 | 7 BAFFLE | 2 | |
| 5T8245 | 8 LADDER AS (RH) | 1 | |
| 5T8269 | 9 PLATE | 1 | |
| 9D4721 | 10 RAIL AS | 1 | |
| 9P2950 | 11 HANDHOLD | 2 | |
| 1148725 | 12 SUPPORT-STEP (RUBBER) | 4 | |
| 1171944 | 13 PLATE | 4 | |
| 1520543 | 14 LADDER AS (LH) | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 5 | |
| 1531315 | 15 HANDHOLD | 2 | |
| 0S1587 | 16 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1595 | 17 BOLT (1/2-13X1.25-IN) | 1 | |
| 0S1621 | 18 BOLT (1/2-13X1-IN) | 1 | |
| 1A5822 | 19 BOLT (1/2-13X2.75-IN) | 2 | |
| 1D4692 | 20 BOLT-CARRIAGE (1/2-13X2.75-IN) | 24 | |
| 1F7958 | 21 NUT-FULL (1/2-13-THD) | 2 | |
| 1K6872 | 22 LOCKNUT (1/2-13-THD) | 24 | |
| 2S1654 | 23 WASHER (3.5X44.5X6-MM THK) | 2 | |
| 4L6454 | 24 BOLT (3/8-16X1-IN) | 10 | |
| 4L9337 | 25 BOLT (3/8-16X1.5-IN) | 8 | |
| 5C6565 | 26 BOLT (1/2-13X1.125-IN) | 4 | |
| 5P1075 | 27 WASHER-HARD (10.2X22.5X3-MM THK) | 14 | |
| 5P1076 | 28 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 5P2228 | 29 BOLT (1/2-13X1-IN) | 8 | |
| 5P8245 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 5S7349 | 31 BOLT (1/4-20X0.5-IN) | 5 | |
| 6V8188 | 32 NUT (1/2-13-THD) | 2 | |
| 6V8801 | 33 NUT (3/8-16-THD) | 12 | |
| 7D1649 | 34 WASHER-HARD (13.5X32X5-MM THK) | 3 | |
| 7X0618 | 35 WASHER-HARD (13.5X40X5-MM THK) | 4 | |
| 8T2502 | 36 BOLT (3/8-16X1.125-IN) | 8 | |
| 8T4205 | 37 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 8T4222 | 38 WASHER-PLATED (11X32X2.5-MM THK) | 4 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 8T4896 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 20 |
