System And Components
434-8078 LINES GP-PUMPS/N SZS1-UP
Group No: 434-8078 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P4868 | 1 CLAMP-HOSE | 4 | |
| 6E1926 | 2 ADAPTER | 1 | |
| 5P1295 | 3 HOSE (13-CM) | ||
| 5P1295 | 3A HOSE (10-CM) | ||
| 6V0852 | 4 CAP-DUST | 1 | |
| 8X8813 | 6 ELBOW | 1 | |
| 9T5957 | 7 VALVE GP-COMBINATION | 1 | |
| 1044286 | 8 TUBE | 1 | |
| 1064684 | 9 BRACKET | 1 | |
| 3378784 | 10 TEE AS | 1 | |
| 8C3309 | TEE | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 4391826 | 11 CONNECTOR AS | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 4742617 | 12 TEE AS | 1 | |
| 6V9835 | TEE | 1 | |
| 2287088 | SEAL-O-RING | 2 | |
| 5416632 | 13 CLIP (LOOP) | 4 | |
| 0673045 | 14 CLIP (LOOP) | 2 | |
| 0927385 | 15 CLIP | 1 | |
| 1017402 | 16 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 1 | |
| 1129787 | 17 HOSE AS | 1 | |
| 1488323 | 18 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9875 | CONNECTOR | 1 | |
| 1488327 | 19 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488347 | 20 ELBOW AS | 7 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1536237 | 21 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645567 | 22 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1S6420 | 23 CLIP | 1 | |
| 2530912 | 24 HOSE AS | 1 | |
| 2611108 | 25 HOSE AS | 1 | |
| 3139198 | 26 CLIP | 1 | |
| 3196698 | 27 BOLT (M12X1.75X110-MM) | 3 | |
| 3353982 | 28 ELBOW AS | 2 | |
| 6V8627 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3445675 | 29 NUT (M10X1.5-THD) | 5 | |
| 4J0521 | 30 SEAL-O-RING | 2 | |
| 4K8864 | 31 CLIP (LOOP) | 1 | |
| 5702502 | 32 HOSE AS | 1 | |
| 5702503 | 33 HOSE AS | 1 | |
| 5702504 | 34 HOSE AS | 1 | |
| 5721758 | 35 ADAPTER AS | 1 | |
| 6V9010 | CONNECTOR-PORT | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 5721759 | 36 ELBOW AS | 1 | |
| 8C8408 | ELBOW | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 5H8848 | 37 SEAL-O-RING | 1 | |
| 5P7854 | 38 CLIP (LOOP) | 1 | |
| 6D4244 | 39 CLIP (LOOP) | 2 | |
| 8T4121 | 40 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 41 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 42 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4185 | 43 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4196 | 44 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 45 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4956 | 46 BOLT (M12X1.75X35-MM) | 4 | |
| 8T6868 | 47 BOLT (M12X1.75X80-MM) | 1 | |
| 8W3166 | 48 HOSE AS | 1 | |
| 8X7820 | 49 HOSE AS | 1 | |
| 9C2399 | 50 HOSE AS | 1 | |
| 9C5344 | 51 SPACER (10.5X20X18-MM THK) | 1 |
