System And Components
5T-0885 TANK GP-AIR -CHASSIS-CHASSISS/N 1HW1-UP
Group No: 5T-0885
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0399 | 1 U-BOLT | 2 | |
| 1D4719 | 2 NUT-FULL (1/2-13-THD) | 4 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5T1049 | 3 TANK-AIR | 1 | |
| 6B9664 | 4 VALVE-AIR RELIEF (AIR TANK) | 1 | |
| 4S7606 | 5 ELBOW | 1 | |
| 5P6011 | 6 TUBE (.2M 7.87IN.) | ||
| 5P4423 | 7 ELBOW | 1 | |
| 4D0487 | 8 VALVE AS-CHECK (AIR TANK) | 1 | |
| 4J3914 | 9 ELBOW | 1 | |
| 5D7464 | 10 HOSE AS (37.8CM 14.88IN.) | 1 | |
| 3R4825 | 11 VALVE GP-AIR CONTROL (AIR TANK)(DRAIN) | 1 | |
| 3R5862 | BUTTON | 1 | |
| 2K3455 | 12 PIN-SPRING | 1 | |
| 4D1138 | 13 VALVE-INLET | 1 | |
| 4J3958 | 14 NUT-CAP | 1 | |
| 4J3957 | 15 SPRING | 1 | |
| 4D1135 | 16 SEAT-SPRING | 1 | |
| 3H0442 | 17 SEAL-O-RING | 1 |
