System And Components
322-2320 LINES GP-PUMPS/N SZN1-UP
Group No: 322-2320
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P4868 | 1 CLAMP-HOSE | 4 | |
| 6E1926 | 2 ADAPTER | 1 | |
| 5P1295 | 3 HOSE (13-CM) | ||
| 5P1295 | 3A HOSE (10-CM) | ||
| 7X2550 | 4 BOLT (M12X1.75X110-MM) | 3 | |
| 8W3166 | 6 HOSE AS | 1 | |
| 9C2399 | 7 HOSE AS | 1 | |
| 9T5957 | 8 VALVE GP-COMBINATION | 1 | |
| 1023659 | 9 ELBOW | 1 | |
| 1044286 | 10 TUBE | 1 | |
| 1064684 | 11 BRACKET | 1 | |
| 1645567 | 12 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2530912 | 13 HOSE AS | 1 | |
| 2611108 | 14 HOSE AS | 1 | |
| 3378784 | 15 TEE AS | 1 | |
| 8C3309 | TEE | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 4391826 | 16 CONNECTOR AS | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 4742617 | 17 TEE AS | 1 | |
| 6V9835 | TEE | 1 | |
| 2287088 | SEAL-O-RING | 2 | |
| 5416632 | 18 CLIP (LOOP) | 4 | |
| 0927385 | 19 CLIP | 1 | |
| 1017402 | 20 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 1 | |
| 1099771 | 21 HOSE AS | 1 | |
| 1129787 | 22 HOSE AS | 1 | |
| 1448344 | 23 SPACER (11X19X20-MM THK) | 1 | |
| 1488323 | 24 CONNECTOR AS | 1 | |
| 6V9875 | CONNECTOR | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1488327 | 25 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488347 | 26 ELBOW AS | 5 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488364 | 27 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488381 | 28 ELBOW AS | 1 | |
| 8T5429 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1536237 | 29 ELBOW AS | 2 | |
| 6V9004 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1H8720 | 30 SEAL-O-RING | 1 | |
| 1S6420 | 31 CLIP | 1 | |
| 3139198 | 32 CLIP | 1 | |
| 3353982 | 33 ELBOW AS | 2 | |
| 6V8627 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3445675 | 34 NUT (M10X1.5-THD) | 5 | |
| 4J0521 | 35 SEAL-O-RING | 2 | |
| 4K8864 | 36 CLIP (LOOP) | 1 | |
| 5416625 | 37 CLIP (LOOP) | 2 | |
| 5702502 | 38 HOSE AS | 1 | |
| 5702503 | 39 HOSE AS | 1 | |
| 5702504 | 40 HOSE AS | 1 | |
| 5721758 | 41 ADAPTER AS | 1 | |
| 6V9010 | CONNECTOR-PORT | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 5721759 | 42 ELBOW AS | 1 | |
| 8C8408 | ELBOW | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 5P7854 | 43 CLIP (LOOP) | 1 | |
| 6D4244 | 44 CLIP (LOOP) | 2 | |
| 6V0852 | 45 CAP-DUST | 1 | |
| 8T4121 | 46 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4136 | 47 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 48 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4185 | 49 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4186 | 50 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4196 | 51 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 52 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4956 | 53 BOLT (M12X1.75X35-MM) | 4 | |
| 8T6868 | 54 BOLT (M12X1.75X80-MM) | 1 | |
| 9C5344 | 55 SPACER (10.5X20X18-MM THK) | 1 |
