261-8536 LIFT GP-BLADES/N B9T1-122

Group No: 261-8536
Part NumberPart NameQty
7D88751 WASHER-THRUST (2.515X3.62X0.075-IN THK)4
7D88782 WASHER-THRUST (3.015X4.22X0.075-IN THK)4
7D88793 SHIM (0.127-MM THK)8
7D88814 SHIM (0.254-MM THK)6
7D88825 SHIM (0.508-MM THK)2
8D43366 WASHER-THRUST (76.6X146X1.90-MM THK)2
8X51067 STUD-BALL1
8X51078 PIN1
8X51099 BAR AS1
8X5108BUSHING2
1245836BUSHING5
123818710 WASHER-THRUST (76.6X146X1-MM THK)2
201803411 BOLT (M20X2.5X120-MM)6
259262712 BOLT (M12X1.75X40-MM)4
259448313 PIN2
259449214 LOCK2
261853715 ARM AS (LH)1
7D8889BEARING (76.35-MM ID)1
8D8168BEARING (63.65-MM ID)1
261853816 ARM AS (RH)1
7D8889BEARING (76.35-MM ID)1
8D8168BEARING (63.65-MM ID)1
261854117 YOKE AS2
2G8233RING1
261854318 RETAINER2
261854519 PLATE1
261854720 LOCK2
288073521 BOLT (M12X1.75X60-MM)1
112392622 BOLT (M20X2.5X110-MM)4
267350823 WASHER-HARD (22X35X3.5-MM THK)16
279663224 WASHER (13.5X25.5X3-MM THK)5
286074225 NUT (M20X2.5-THD)6
3P146126 SEAL-LIP TYPE4
5F014927 SEAL-O-RING2
7D887628 WASHER-THRUST (65.07X92.08X2.39-MM THK)2
7D887729 WASHER-THRUST (77.77X107.19X2.39-MM THK)2
7D888330 SEAL2
7D888431 SEAL2
7H244432 SEAL-O-RING2
