System And Components
330-3562 TANK GP-FUEL -LHS/N B9M1-UP
Group No: 330-3562
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 7X7700 | 2 CAP AS-FUEL (LOCKABLE, VENTED) | 1 | |
| 9X2205 | KIT-CAP FILTER (FUEL TANK) | 1 | |
| 9X8600 | SEAL-O-RING | 1 | |
| 1999907 | 3 STRAINER-FUEL | 1 | |
| 2509304 | 4 PLATE | 1 | |
| 2763276 | 5 GASKET | 1 | |
| 2887312 | 6 VENT AS | 1 | |
| 2961302 | 7 VENT AS | 1 | |
| 3303566 | 8 GASKET | 2 | |
| 3303568 | 9 GASKET | 1 | |
| 3303570 | 10 TANK AS-FUEL (LH) | 1 | |
| 1622165 | 11 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 14 | |
| 2691021 | 12 SENDER AS-FUEL LEVEL (WITH GAUGE) | 1 | |
| 6C3060 | GASKET | 1 | |
| 3179191 | KIT-DIAL SENSOR (FUEL LEVEL GAUGE) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 3068127 | 13 ADAPTER | 1 | |
| 3293707 | 14 SCREW-PAN HEAD (6X0.375-IN) | 1 | |
| 4B4863 | 15 WASHER (4.7X11X1.2-MM THK) | 14 | |
| 8T4189 | 16 BOLT (M8X1.25X20-MM) | 12 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 9M7958 | 18 CLAMP-HOSE | 2 | |
| 1467453 | 19 HOSE (113-CM) | ||
| 1497372 | 20 SLEEVE-ABRASION (103-CM) |
