System And Components
253-1967 WIRING GP-MONITOR -CD610S/N B9M1-UP
Group No: 253-1967
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0950817 | 1 LOCKWASHER | 2 | |
| 1678712 | 2 ALARM | 1 | |
| 1678713 | 3 BAFFLE AS | 1 | |
| 1678714 | 4 WIRE AS | 1 | |
| 2482284 | 5 KNOB-CONTROL | 2 | |
| 2510077 | 6 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2519571 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2958963 | 8 PLATE | 1 | |
| 2964922 | 9 HARNESS AS-MONITOR | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 9X6772 | STRAP-CABLE | 2 | |
| 1261774 | COVER-CONNECTOR | 1 | |
| 1471444 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1305300 | 10 CLIP | 3 | |
| 4L7125 | 11 LOCKWASHER | 4 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4171 | 13 BOLT (M6X1X12-MM) | 4 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P7657 | 15 SEAL (0.2-M) |
