System And Components
236-7296 PUMP GP-PISTON -IMPLEMENT, STEERINGS/N D9G1-1185
Group No: 236-7296
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6E4224 | 1 PLUG-SWASHPLATE | 1 | |
| 0336036 | 2 SEAL-O-RING | 1 | |
| 1003402 | 3 BEARING-SWASH | 1 | |
| 1003405 | 4 BEARING-SWASH | 1 | |
| 6V8837 | 5 BOLT (M6X1X16-MM) | 3 | |
| 4F4097 | 6 SEAL-O-RING | 1 | |
| 3E4302 | 7 SCREW-FLAT HEAD (M4X0.7X10-MM) | 2 | |
| 1003404 | 8 COVER-TRUNNION | 1 | |
| 9T1636 | 9 SEAT | 1 | |
| 9T1710 | 10 POPPET | 1 | |
| 9T1699 | 11 SPRING | 1 | |
| 6V7673 | 12 BOLT (M12X1.75X50-MM) | 3 | |
| 6E1436 | 13 SHIM PACK (INCLUDES 17-SHIMS) | 1 | |
| 6Y4280 | 14 CONE-BEARING | 1 | |
| 7T9755 | 15 CUP-BEARING | 1 | |
| 9T9460 | 16 PLATE-VALVE | 1 | |
| 3E7417 | 17 PLUG | 3 | |
| 8T7876 | 18 SEAL-O-RING | 3 | |
| 7L9061 | 19 SEAL-O-RING | 2 | |
| 1003413 | 20 GASKET | 1 | |
| 1003412 | 21 ROTATING GP-PUMP | 1 | |
| 1003409 | 22 SPRING-BIAS | 1 | |
| 1003408 | 23 KIT-BIAS PISTON | 1 | |
| 0021212 | 24 CUP-BEARING | 1 | |
| 2F8509 | 25 CONE-BEARING | 1 | |
| 1022066 | 26 SHAFT-PUMP | 1 | |
| 8T5039 | 27 SEAL-O-RING | 3 | |
| 0068663 | 28 RING | 2 | |
| 8T4750 | 29 SEAL-LIP TYPE | 2 | |
| 1693290 | 30 SWASHPLATE GP | 1 | |
| 1003415 | 31 KIT-CONTROL PISTON | 1 | |
| 9T1652 | 32 PIN | 1 | |
| 8T0372 | 33 BOLT (M12X1.75X90-MM) | 1 | |
| 8T7811 | 34 BOLT-SOCKET HEAD (M12X1.75X50-MM) | 1 | |
| 6V8336 | 35 BOLT (M12X1.75X70-MM) | 1 | |
| 6V8337 | 36 BOLT-SOCKET HEAD (M8X1.25X35-MM) | 4 | |
| 2716847 | 37 VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR)(IMPLEMENT) | 1 | |
| 9S4190 | 38 PLUG-O-RING (7/8-14-THD) | 1 | |
| 0336027 | 39 SEAL-O-RING | 1 | |
| 0950888 | 40 PIN-SPRING | 2 |
