System And Components
9T-1383 TANK & FILTER GP-HYDRAULICS/N 9BL1-1799
Group No: 9T-1383
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3G6014 | 1 TANK AS | 1 | |
| 9T1382 | 2 TANK AS | 1 | |
| 2K4973 | 3 LOCKNUT (3/8-16-THD) | 73 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 38 | |
| 5F3092 | 5 SEAL-O-RING | 1 | |
| 0L1351 | 6 BOLT (3/8-16X0.875-IN) | 2 | |
| 5H6733 | 7 SEAL-O-RING | 2 | |
| 9T1380 | 8 COVER | 2 | |
| 9T1373 | 9 GUIDE | 2 | |
| 5P8245 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 9J6379 | 11 SPRING-DISC | 12 | |
| 9H7759 | 12 RING-RETAINING | 2 | |
| 9J6381 | 13 SPACER (71X108X3-MM THK) | 2 | |
| 6V0852 | 14 CAP-DUST | 1 | |
| 6V3965 | 15 FITTING (QUICK DISCONNECT) | 1 | |
| 3G5979 | 16 ADAPTER | 3 | |
| 5M5860 | 17 SEAL-O-RING | 4 | |
| 4B7739 | 18 PLUG-DRAIN | 1 | |
| 9T1376 | 19 TUBE AS | 1 | |
| 2B0858 | 20 PLUG-PIPE | 1 | |
| 4J0521 | 21 SEAL-O-RING | 1 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 60 | |
| 3G3824 | 23 TUBE AS | 1 | |
| 5D0353 | 24 BOLT-LOCKING (3/8-16X1-IN) | 4 | |
| 3G3823 | 25 FLANGE | 1 | |
| 3G3820 | 26 SPRING | 1 | |
| 3G3821 | 27 VALVE | 1 | |
| 7K5636 | 28 COVER GP-XMSN OIL FILLER CAP | 1 | |
| 5F7054 | 29 SEAL-O-RING | 20 | |
| 9T1379 | 31 BASE (FILTER) | 1 | |
| 5K7143 | 32 BOLT-SELF-LOCKING (1/2-13X1.5-IN) | 4 | |
| 2H3927 | 33 SEAL-O-RING | 2 | |
| 3G5978 | 34 TUBE | 1 | |
| 1R0722 | 35 FILTER ELEMENT AS-OIL (STANDARD EFFICIENCY) | 2 | |
| 3G5018 | 36 ELBOW | 1 | |
| 3G6017 | 37 COVER | 1 | |
| 6F0711 | 38 SEAL-O-RING | 2 | |
| 2S4078 | 39 SEAL-O-RING | 2 | |
| 4B9302 | 40 CLIP (LOOP) | 1 | |
| 9S9238 | 41 SPACER (13.49X23.88X16.13-MM THK) | 1 | |
| 8M4446 | 42 SEAL-O-RING | 2 | |
| 3B1915 | 43 BOLT (3/8-16X1.375-IN) | 10 | |
| 2J0157 | 44 SEAL-O-RING | 2 | |
| 1A2029 | 45 BOLT (3/8-16X1.125-IN) | 7 | |
| 4F7390 | 46 SEAL-O-RING | 2 | |
| 9S4183 | 47 PLUG (1-1/16-12-THD) | 3 | |
| 3D2824 | 48 SEAL-O-RING | 4 | |
| 0S1587 | 49 BOLT (1/2-13X1.75-IN) | 4 | |
| 0S1585 | 53 BOLT (1/2-13X1.5-IN) | 3 | |
| 9S4191 | 56 PLUG (9/16-18-THD) | 2 | |
| 3J1907 | 57 SEAL-O-RING | 3 | |
| 9S4185 | 58 PLUG (3/4-16-THD) | 2 | |
| 3K0360 | 59 SEAL-O-RING | 2 | |
| 5H8038 | 60 SEAL-O-RING | 1 | |
| 1369768 | 61 TUBE | 1 | |
| 4T5864 | 62 BLOCK | 1 | |
| 0L1143 | 63 BOLT (3/8-16X2.5-IN) | 2 | |
| 1677513 | 64 BLOCK | 1 | |
| 1U2819 | 65 TUBE AS | 1 | |
| 4T3176 | 66 VALVE GP-COOLER BYPASS | 1 | |
| 9S8010 | 67 PLUG | 2 | |
| 3H2652 | 68 SEAL-O-RING | 2 | |
| 3G8101 | 69 TUBE | 1 | |
| 4T0355 | 70 MANIFOLD | 1 | |
| 5P9119 | 71 GASKET-TAPE (ADHESIVE BACKED) | ||
| 4B9782 | 72 BALL | 1 | |
| 6H5139 | 73 PLATE-PRESSURE | 1 | |
| 9H6454 | 74 GASKET | 1 | |
| 9J3047 | 75 STRAINER | 1 | |
| 3G0361 | 76 GASKET | 1 | |
| 5K1568 | 77 CAP-FILLER (HYDRAULIC OIL) | 1 | |
| 0T0055 | 78 BOLT (3/8-16X4.25-IN) | 4 | |
| 3G4683 | 79 RETAINER | 1 | |
| 3G4770 | 80 GLASS-SIGHT (HYDRAULIC OIL LEVEL) | 1 | |
| 9F4446 | 81 SEAL-O-RING | 1 | |
| 1U0387 | 82 SPACER-SPECIAL | 1 | |
| 2M4453 | 83 SEAL-O-RING | 2 | |
| 3G4771 | 84 PLATE | 1 | |
| 2K3219 | 85 SCREW-DRIVE (NO 6X0.25-IN) | 2 | |
| 9S8008 | 86 PLUG (1-1/16-12-THD) | 1 | |
| 3G4708 | 87 ADAPTER | 1 | |
| 8M4991 | 88 SEAL-O-RING | 1 |
