System And Components
9T-1384 TANK & FILTER GP-HYDRAULICS/N 86G3000-3252
Group No: 9T-1384
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3G6014 | 1 TANK AS | 1 | |
| 9T1382 | 2 TANK AS | 1 | |
| 5P9119 | 3 GASKET-TAPE (ADHESIVE BACKED) | ||
| 9J5461 | 4 FILTER ELEMENT AS-OIL (HYDRAULIC) | 2 | |
| 5P8245 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9J6379 | 6 SPRING-DISC | 12 | |
| 9J6381 | 7 SPACER (71X108X3-MM THK) | 2 | |
| 9H7759 | 8 RING-RETAINING | 2 | |
| 6V0852 | 9 CAP-DUST | 1 | |
| 6V3965 | 10 FITTING (QUICK DISCONNECT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3G5979 | 11 ADAPTER | 1 | |
| 5M5860 | 12 SEAL-O-RING | 1 | |
| 2K4973 | 13 LOCKNUT (3/8-16-THD) | 64 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5K7143 | 15 BOLT-SELF-LOCKING (1/2-13X1.5-IN) | 4 | |
| 4B7739 | 16 PLUG-DRAIN | 1 | |
| 9T1376 | 17 TUBE AS | 1 | |
| 2B0858 | 18 PLUG-PIPE | 1 | |
| 3B1915 | 19 BOLT (3/8-16X1.375-IN) | 2 | |
| 4J0521 | 20 SEAL-O-RING | 1 | |
| 9T1379 | 21 BASE (FILTER) | 1 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 60 | |
| 3G3824 | 23 TUBE AS | 1 | |
| 5D0353 | 24 BOLT-LOCKING (3/8-16X1-IN) | 2 | |
| 3G3823 | 25 FLANGE | 1 | |
| 3G3820 | 26 SPRING | 1 | |
| 3G3821 | 27 VALVE | 1 | |
| 5F7054 | 28 SEAL-O-RING | 4 | |
| 7K5636 | 29 COVER GP-XMSN OIL FILLER CAP (TRANSMISSION) | 1 | |
| 3G4708 | 30 ADAPTER | 1 | |
| 8M4991 | SEAL-O-RING | 1 | |
| 2K4973 | 31 LOCKNUT (3/8-16-THD) | 6 | |
| 5M2894 | 32 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 3G5978 | 33 TUBE | 1 | |
| 3G5018 | 34 ELBOW | 1 | |
| 5K1568 | 35 CAP-FILLER | 1 | |
| 4B9782 | BALL | 1 | |
| 6H5139 | 36 PLATE-PRESSURE | 1 | |
| 9H6454 | 37 GASKET | 1 | |
| 9J3047 | 38 STRAINER | 1 | |
| 3G0361 | 39 GASKET | 1 | |
| 9S8008 | 40 PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9T1380 | 41 COVER | 2 | |
| 5H6733 | SEAL-O-RING | 2 | |
| 9S8010 | 42 PLUG | 2 | |
| 2S4078 | SEAL-O-RING | 2 | |
| 0T0055 | 43 BOLT (3/8-16X4.25-IN) | 4 | |
| 3G4683 | 44 RETAINER | 1 | |
| 3G4770 | 45 GLASS-SIGHT (HYDRAULIC OIL LEVEL) | 1 | |
| 9F4446 | SEAL-O-RING | 1 | |
| 3G4771 | PLATE | 1 | |
| 2K3219 | SCREW-DRIVE (NO 6X0.25-IN) | 2 | |
| 0L1351 | 46 BOLT (3/8-16X0.875-IN) | 2 | |
| 3G5979 | 47 ADAPTER | 2 | |
| 5M5860 | 48 SEAL-O-RING | 2 | |
| 9S4191 | 49 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2H3927 | 50 SEAL-O-RING | 2 | |
| 3B1915 | 51 BOLT (3/8-16X1.375-IN) | 8 | |
| 9T1373 | 52 GUIDE | 2 | |
| 1U0387 | 53 SPACER-SPECIAL | 1 | |
| 2M4453 | SEAL-O-RING | 2 | |
| 5F7054 | 54 SEAL-O-RING | 16 | |
| 1A2029 | 55 BOLT (3/8-16X1.125-IN) | 7 | |
| 5M2894 | 56 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 4T5864 | 57 BLOCK | 1 | |
| 6F0711 | 58 SEAL-O-RING | 2 | |
| 0S1587 | 59 BOLT (1/2-13X1.75-IN) | 4 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5F3092 | 60 SEAL-O-RING | 1 | |
| 2K4973 | 61 LOCKNUT (3/8-16-THD) | 3 | |
| 4F7390 | 62 SEAL-O-RING | 2 | |
| 4B9302 | 63 CLIP (LOOP) | 1 | |
| 9S9238 | 64 SPACER (13.49X23.88X16.13-MM THK) | 1 | |
| 0L1143 | 65 BOLT (3/8-16X2.5-IN) | 2 | |
| 1U2821 | 66 BLOCK | 1 | |
| 1U2819 | 67 TUBE AS | 1 | |
| 2J0157 | 68 SEAL-O-RING | 2 | |
| 8M4446 | 69 SEAL-O-RING | 2 | |
| 5D0353 | 70 BOLT-LOCKING (3/8-16X1-IN) | 2 | |
| 5M5860 | 71 SEAL-O-RING | 1 | |
| 5H8038 | 72 SEAL-O-RING | 1 | |
| 1U2817 | 73 TUBE | 1 | |
| 4T3177 | 74 VALVE GP-COOLER BYPASS | 1 | |
| 4T0355 | 75 MANIFOLD | 1 | |
| 3H2652 | 76 SEAL-O-RING | 2 | |
| 3G8101 | 77 TUBE | 1 | |
| 9S4185 | 78 PLUG (3/4-16-THD) | 2 | |
| 3K0360 | SEAL-O-RING | 2 | |
| 9S4191 | 79 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0S1585 | 80 BOLT (1/2-13X1.5-IN) | 3 | |
| 9S4183 | 81 PLUG (1-1/16-12-THD) | 3 | |
| 3D2824 | SEAL-O-RING | 3 | |
| 3G6017 | 82 COVER | 1 | |
| 3G8099 | 83 COVER | 1 | |
| 3G8100 | GASKET | 1 |
