8X-7706 WIRING GP-ENGINES/N 8MN1-459

Group No: 8X-7706

Part Number	Part Name	Qty
9W3187	1 SWITCH AS-PRESSURE (FUEL)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
4D7794	2 CLIP	3
3B8822	3 ELBOW	1
1018174	4 HARNESS AS-ENGINE	1
8T4224	5 WASHER-HARD (8.8X16X2-MM THK)	5
0338248	6 CLIP (LOOP)	1
8T5391	7 BOLT (5/16-18X0.5-IN)	4
7C4354	8 CLIP	1
8M2773	9 CLIP (LOOP)	1
6T2217	10 RESISTOR AS	1
7N7779	SOCKET-CONNECTOR (14-GA TO 18-GA)	1
7N7780	PIN-CONNECTOR (14-GA TO 18-GA)	1
7N9737	HOUSING-RECEPTACLE (14-GA TO 18-GA)	1
3T3048	11 CLIP AS	3
3S2093	12 STRAP-CABLE	2
9M4594	13 SPACER (0.406X0.875X0.75-IN THK)	1
8M2770	14 CLIP (LOOP)	1
9G9154	15 CLIP	1
3T0050	16 CLIP	1
8C3121	17 BOLT (5/16-18X1.5-IN)	1
9G9150	18 CLIP (TAB)	2
9M8406	19 CLIP (LOOP)	1
6V5782	20 BOLT (5/16-18X1.125-IN)	1
8T9043	21 BOLT (5/16-18X0.875-IN)	2
8T4224	22 WASHER-HARD (8.8X16X2-MM THK)	2
6V8189	23 NUT (5/16-18-THD)	2
8B8679	24 SPACER (0.406X0.75X0.44-IN THK)	1
8T8911	25 BOLT (5/16-18X2-IN)	1
8T4896	26 WASHER-HARD (10.2X18.5X2.5-MM THK)	1
8T9101	27 BOLT (3/8-16X2.75-IN)	1
7N9785	28 SWITCH AS-TEMPERATURE (COOLANT)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
9M8406	29 CLIP (LOOP)	2
8T4224	30 WASHER-HARD (8.8X16X2-MM THK)	4
8T5391	31 BOLT (5/16-18X0.5-IN)	4
9G9150	32 CLIP (TAB)	2
8M2773	33 CLIP (LOOP)	1
6D4244	34 CLIP (LOOP)	1
8M2770	35 CLIP (LOOP)	3
3J1907	36 SEAL-O-RING	1
9X0378	37 SWITCH AS-PRESSURE (ENGINE OIL)	1
7N7779	SOCKET-CONNECTOR (14-GA TO 18-GA)	1
7N7780	PIN-CONNECTOR (14-GA TO 18-GA)	1
7N9738	HOUSING-RECEPTACLE (14-GA TO 18-GA)	1
6V9601	38 ADAPTER	1
7N8532	39 SENDER AS-TEMPERATURE (12-VOLT)(COOLANT)	1
3S2093	40 STRAP-CABLE	1
1058687	41 PLATE	1
9G4360	42 CAP-CONNECTOR	1
8T4896	43 WASHER-HARD (10.2X18.5X2.5-MM THK)	1
5M3062	44 BOLT (3/8-16X0.75-IN)	1
1140931	45 FILM-IDENTIFICATION (SERVICE CONNECTOR)	1
8T9043	46 BOLT (5/16-18X0.875-IN)	1
8T4224	47 WASHER-HARD (8.8X16X2-MM THK)	1
6V8189	48 NUT (5/16-18-THD)	1
