System And Components
246-6706 LINES GP-FUEL FILTERS/N B551-UP
Group No: 246-6706
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 1845394 | 2 CLIP (LOOP) | 1 | |
| 1901105 | 3 PUMP GP-FILTER & FUEL TRANSFER | 1 | |
| 4204900 | 5 BRACKET AS | 1 | |
| 4Y8939 | BOSS (M10X1.5X40-MM) | 1 | |
| 9R2821 | BOSS (M10X1.5X15-MM) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4202896 | 6 HOSE AS | 1 | |
| 2775431 | 7 HOSE AS | 1 | |
| 2890213 | 8 BRACKET | 1 | |
| 3537954 | 9 GROMMET | 2 | |
| 0307962 | 10 ELBOW | 1 | |
| 1488372 | 12 ELBOW AS | 1 | |
| 6V8721 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 3309757 | 13 ELBOW AS | 1 | |
| 8T1905 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1645557 | 14 CONNECTOR AS | 1 | |
| 5I4370 | CONNECTOR | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488364 | 15 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T1890 | 16 CLIP (TAB) | 2 | |
| 4363331 | 17 HOSE AS | 1 | |
| 1S0994 | 18 CLIP (LOOP) | 2 | |
| 4D7735 | 19 CLIP | 1 | |
| 5C7261 | 20 NUT (M8X1.25-THD) | 1 | |
| 5P4116 | 21 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 5P9299 | 22 CLIP (LOOP) | 1 | |
| 7X7729 | 23 WASHER (11X25X3-MM THK) | 13 | |
| 8M2773 | 24 CLIP (LOOP) | 1 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4133 | 26 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 27 BOLT (M10X1.5X25-MM) | 7 | |
| 8T1889 | 28 CLIP (SLOT) | 2 | |
| 8T4195 | 29 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4196 | 30 BOLT (M10X1.5X35-MM) | 5 | |
| 8C6959 | 31 HOSE (108-CM) | ||
| 4P7581 | 32 CLIP (LADDER) | 1 | |
| 7K1181 | 33 STRAP-CABLE | 1 | |
| 0964883 | 36 LOCKNUT (M10X1.5-THD) | 2 | |
| 4201867 | 37 HOSE AS | 1 | |
| 4194129 | 38 FILTER GP-FUEL | 1 | |
| 4317841 | 39 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1488354 | 40 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 |
