System And Components
288-8988 ENCLOSURE GP-ENGINES/N B9M925-UP
Group No: 288-8988
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X1387 | 1 WASHER (10.26X22.22X1.9-MM THK) | 9 | |
| 2273101 | 2 STRIKER AS | 2 | |
| 2273103 | 3 PLATE | 2 | |
| 2452806 | 4 HANDHOLD | 2 | |
| 2452827 | 5 HANDRAIL | 2 | |
| 2675503 | 6 HANDRAIL | 2 | |
| 2840565 | 7 GUARD AS | 1 | |
| 2859034 | 8 ROD AS | 2 | |
| 2859036 | 9 ROD AS | 1 | |
| 2861605 | 10 PLATE | 3 | |
| 2889013 | 11 DOOR AS (RH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3047620 | BUMPER | 4 | |
| 2889017 | 12 DOOR AS (LH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3047620 | BUMPER | 4 | |
| 2889588 | 13 HOOD GP (ENGINE) | 1 | |
| 2923091 | 14 BAR | 2 | |
| 2923092 | 15 COVER AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 2951578 | 16 BRACKET AS | 2 | |
| 2953839 | 17 PAWL | 3 | |
| 3087777 | 18 PLATE | 2 | |
| 3160557 | 19 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 13 | |
| 3186433 | 20 PANEL AS-ENCLOSURE | 1 | |
| 3211371 | 21 PANEL AS | 1 | |
| 3211376 | 22 PANEL AS | 1 | |
| 3211446 | 23 BRACKET AS | 1 | |
| 3213884 | 24 HINGE AS | 2 | |
| 3217238 | 25 PANEL | 1 | |
| 3221172 | 26 PLATE AS | 1 | |
| 3231776 | 27 BRACKET AS | 1 | |
| 3231779 | 28 FRAME AS (LH) | 1 | |
| 3231780 | 29 FRAME AS (RH) | 1 | |
| 3232550 | 30 FRAME AS | 1 | |
| 3232551 | 31 PLATE AS | 1 | |
| 3260610 | 32 LATCH AS | 3 | |
| 3445673 | NUT (M6X1-THD) | 4 | |
| 1H3244 | LOCKWASHER | 4 | |
| 0951207 | NUT (M12X1.75-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3480424 | 33 DOOR AS (LH) | 1 | |
| 3047620 | BUMPER | 4 | |
| 3213884 | HINGE AS | 1 | |
| 3495332 | 34 DASH AS | 1 | |
| 3496273 | 35 PLATE AS | 1 | |
| 1984777 | 36 WASHER-HARD (11X25X10-MM THK) | 10 | |
| 1984778 | 37 WASHER-HARD (13.5X30X12-MM THK) | 4 | |
| 3B4615 | 38 PIN-COTTER | 9 | |
| 5C7261 | 39 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 40 WASHER-HARD (8.8X20.5X2-MM THK) | 15 | |
| 5P8439 | 41 GROMMET | 3 | |
| 6P6256 | 42 RETAINER-SPRING | 2 | |
| 6V7744 | 43 LOCKNUT (M10X1.5-THD) | 3 | |
| 7X7729 | 44 WASHER (11X25X3-MM THK) | 121 | |
| 8T4133 | 45 NUT (M10X1.5-THD) | 18 | |
| 8T4136 | 46 BOLT (M10X1.5X25-MM) | 76 | |
| 8T4184 | 47 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4189 | 48 BOLT (M8X1.25X20-MM) | 47 | |
| 8T4195 | 49 BOLT (M10X1.5X30-MM) | 36 | |
| 8T4196 | 50 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4224 | 51 WASHER-HARD (8.8X16X2-MM THK) | 47 | |
| 8T4908 | 52 BOLT (M8X1.25X25-MM) | 11 | |
| 6V5746 | 53 TRIM (0.6-M) | ||
| 8T4222 | 54 WASHER-PLATED (11X32X2.5-MM THK) | 2 |
