System And Components
355-0046 LINES GP-FUEL FILTERS/N TXG1-UP; LHX25172-UP
Group No: 355-0046
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 2270181 | 2 TUBE AS | 1 | |
| 2474223 | 3 BRACKET AS | 1 | |
| 3547738 | 4 HARNESS AS-SENSOR | 1 | |
| 2480903 | 5 HOSE AS | 1 | |
| 2480904 | 6 HOSE AS | 1 | |
| 2480905 | 7 HOSE AS | 1 | |
| 2480906 | 8 HOSE AS | 1 | |
| 2801472 | 9 PLATE AS | 1 | |
| 2801473 | 10 PLATE AS-FUEL FILTER MOUNTING | 1 | |
| 0L1351 | 11 BOLT (3/8-16X0.875-IN) | 3 | |
| 0S1588 | 12 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1591 | 13 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 1 | |
| 0T0573 | 15 BOLT (3/8-16X2.75-IN) | 1 | |
| 1C2251 | 16 BOLT (3/8-16X1.87-IN) | 4 | |
| 3196225 | 17 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3E4353 | 18 WASHER-HARD (11X25X3-MM THK) | 1 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P7462 | 20 CLIP (SLOT) | 1 | |
| 5P7463 | 21 CLIP (TAB) | 1 | |
| 6V0683 | 22 GROMMET | 1 | |
| 6V6317 | 23 BOLT (M10X1.5X20-MM) | 1 | |
| 3196213 | 24 CONNECTOR AS | 2 | |
| 6V8634 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 1833399 | 25 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2501424 | 26 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3920777 | 27 CONNECTOR AS | 1 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 6V9168 | 28 NUT (11/16-16-THD) | 1 | |
| 6W6672 | 29 SPACER (10.5X20X38-MM THK) | 1 | |
| 7V6571 | 30 GROMMET | 5 | |
| 8T1889 | 31 CLIP (SLOT) | 5 | |
| 8T1890 | 32 CLIP (TAB) | 5 | |
| 3309757 | 33 ELBOW AS | 1 | |
| 8T1905 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 9R1004 | 34 CLIP (TAB) | 1 | |
| 9R1005 | 35 CLIP (SLOT) | 1 | |
| 9X6458 | 36 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
