System And Components
305-2926 LINES GP-HYDRAULIC -CIRCLE, DRAWBAR, MOLDBOARDS/N R9L1-UP
Group No: 305-2926
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 5P0599 | 2 CLAMP-BAND | 2 | |
| 8W3991 | 3 JUNCTION BLOCK | 2 | |
| 9R8870 | 4 BLOCK | 2 | |
| 2451375 | 5 GUIDE AS-HOSE | 1 | |
| 2466341 | 6 CLAMP | 2 | |
| 2466342 | 7 CLAMP | 8 | |
| 2868181 | 8 HOSE AS | 1 | |
| 2964308 | 9 TUBE AS | 1 | |
| 2964309 | 10 TUBE AS | 1 | |
| 2972813 | 11 TUBE AS | 3 | |
| 2972814 | 12 TUBE AS | 3 | |
| 3128373 | 13 HOSE AS | 1 | |
| 3128381 | 14 HOSE AS | 1 | |
| 3128383 | 15 HOSE AS | 1 | |
| 1645605 | 16 CONNECTOR AS | 2 | |
| 8T0076 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 4841274 | 17 HOSE AS | 1 | |
| 4869093 | 18 HOSE AS | 1 | |
| 3235746 | 19 HOSE AS | 1 | |
| 3653994 | 20 HOSE AS | 1 | |
| 4474049 | 21 CLAMP | 2 | |
| 4474050 | 22 CLAMP | 2 | |
| 1488340 | 23 CONNECTOR AS | 12 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488354 | 24 ELBOW AS | 2 | |
| 6V9002 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488358 | 25 ELBOW AS | 1 | |
| 6V8624 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488364 | 26 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488372 | 27 ELBOW AS | 1 | |
| 6V8721 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488374 | 28 ELBOW AS | 6 | |
| 6V8723 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488318 | 29 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 3445675 | 30 NUT (M10X1.5-THD) | 9 | |
| 4426228 | 31 HOSE AS | 1 | |
| 4505267 | 32 HOSE AS | 1 | |
| 5G3676 | 33 GROMMET | 4 | |
| 6D4246 | 34 CLIP (LOOP) | 2 | |
| 6D4247 | 35 CLIP | 1 | |
| 6V8398 | 36 SEAL-O-RING | 6 | |
| 7X7729 | 37 WASHER (11X25X3-MM THK) | 2 | |
| 8T1887 | 38 CLIP (SLOT) | 2 | |
| 8T1888 | 39 CLIP (TAB) | 2 | |
| 8T1889 | 40 CLIP (SLOT) | 2 | |
| 8T1890 | 41 CLIP (TAB) | 2 | |
| 8T1895 | 42 CLIP (SLOT) | 2 | |
| 8T1896 | 43 CLIP (TAB) | 2 | |
| 8T4121 | 44 WASHER-HARD (11X21X2.5-MM THK) | 33 | |
| 8T4136 | 45 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4137 | 46 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4172 | 47 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4185 | 48 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4186 | 49 BOLT (M10X1.5X40-MM) | 5 | |
| 8T4195 | 50 BOLT (M10X1.5X30-MM) | 6 | |
| 9M4594 | 51 SPACER (0.406X0.875X0.75-IN THK) | 4 | |
| 4841275 | 52 HOSE AS | 1 | |
| 4859584 | 53 HOSE AS | 1 | |
| 1220450 | 54 GROMMET | 1 | |
| 8T1897 | 55 CLIP (SLOT) | 1 | |
| 8T1898 | 56 CLIP (TAB) | 1 | |
| 5416632 | 57 CLIP (LOOP) | 12 |
