System And Components
285-1250 VALVE & MTG GP-MAIN CONTROLS/N B3F2313-UP
Group No: 285-1250
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P6412 | 1 HOSE (12-CM) | ||
| 8T4983 | 2 CLAMP-HOSE | 2 | |
| 8W5090 | 3 HOSE AS | 1 | |
| 1186878 | 4 BRACKET AS | 1 | |
| 1250810 | 5 HOSE AS | 1 | |
| 2354146 | 6 HARNESS AS-VALVE (CONTROL) | 1 | |
| 2413515 | 7 TUBE AS | 1 | |
| 2413516 | 8 TUBE AS | 1 | |
| 2423261 | 9 TUBE AS | 1 | |
| 2423273 | 10 MANIFOLD | 1 | |
| 2908069 | 11 VALVE GP-MAIN CONTROL (7-BANK) | 1 | |
| 2424240 | 12 VALVE GP-CONTROL (INTERMITTENT SAW, 2-BANK) | 1 | |
| 2462204 | 13 TUBE AS | 1 | |
| 2485014 | 14 VALVE GP-CHECK | 1 | |
| 2613578 | 15 HOSE AS | 1 | |
| 2613579 | 16 HOSE AS | 1 | |
| 2613580 | 17 HOSE AS | 1 | |
| 2613583 | 18 HOSE AS | 2 | |
| 2613584 | 19 HOSE AS | 1 | |
| 2613585 | 20 HOSE AS | 1 | |
| 2852267 | 21 BRACKET | 1 | |
| 1488309 | 22 ADAPTER AS | 2 | |
| 2P8421 | ADAPTER-O-RING | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1488334 | 23 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 8T3611 | CONNECTOR | 1 | |
| 1488335 | 24 CONNECTOR AS | 4 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488336 | 25 CONNECTOR AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488353 | 26 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488367 | 27 ELBOW AS | 3 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488378 | 28 ELBOW AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488387 | 29 ELBOW AS | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 6V9855 | ELBOW | 1 | |
| 1488391 | 30 ELBOW AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T8987 | ELBOW | 1 | |
| 1488407 | 31 PLUG AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488409 | 32 PLUG AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 1488429 | 33 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V9840 | TEE-SWIVEL | 1 | |
| 1488433 | 34 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1488434 | 35 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9843 | TEE | 1 | |
| 1488445 | 37 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V9847 | TEE-SWIVEL | 1 | |
| 1503036 | 38 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 1645616 | 39 PLUG AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 9S6130 | PLUG | 1 | |
| 1706541 | 40 ELBOW | 1 | |
| 1P3702 | 41 SEAL-RECTANGULAR | 2 | |
| 1P3703 | 42 SEAL-RECTANGULAR | 3 | |
| 1P4578 | 43 FLANGE-HALF | 2 | |
| 2S4078 | 44 SEAL-O-RING | 1 | |
| 4D7794 | 45 CLIP | 2 | |
| 4J0522 | 46 SEAL-O-RING | 1 | |
| 4S4455 | 47 CLIP | 1 | |
| 5K5338 | 48 CLIP (LOOP) | 3 | |
| 5P0046 | 49 COVER | 2 | |
| 6V0400 | 50 FLANGE-HALF | 2 | |
| 6V8400 | 51 SEAL-O-RING | 2 | |
| 6V9833 | 52 CAP | 1 | |
| 6V9834 | 53 CAP | 1 | |
| 8T4121 | 54 WASHER-HARD (11X21X2.5-MM THK) | 31 | |
| 8T4133 | 55 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 56 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 57 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4182 | 58 BOLT (M10X1.5X45-MM) | 8 | |
| 8T4184 | 59 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4195 | 60 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 61 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4198 | 62 BOLT (M10X1.5X100-MM) | 6 | |
| 8T4223 | 63 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T9403 | 64 FLANGE-HALF | 4 | |
| 9X6279 | 65 SETSCREW-SOCKET (M8X1.25-THD) | 1 |
