System And Components
384-2539 WIRING GP-CHASSIS -FRONT, UPPERS/N RTL1-103
Group No: 384-2539
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4242319 | 1 BLOCK | 2 | |
| 4242322 | 2 BLOCK | 2 | |
| 4242325 | 3 BLOCK | 6 | |
| 4242326 | 4 BLOCK | 8 | |
| 4242327 | 5 BLOCK | 4 | |
| 4242328 | 6 BLOCK | 3 | |
| 4242329 | 7 BLOCK | 7 | |
| 4242332 | 8 BLOCK | 3 | |
| 4242335 | 9 BLOCK | 2 | |
| 4242340 | 10 BLOCK | 11 | |
| 4242341 | 11 BLOCK | 15 | |
| 4242342 | 12 BLOCK | 2 | |
| 4J6301 | 13 TAG-IDENTIFICATION (NUMBER ONE) | 1 | |
| 4J6302 | 14 TAG-IDENTIFICATION (NUMBER TWO) | 1 | |
| 4J6304 | 15 TAG-IDENTIFICATION (NUMBER FOUR) | 1 | |
| 7K1181 | 16 STRAP-CABLE | 2 | |
| 9L1775 | 17 BRACKET | 1 | |
| 1243019 | 18 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1279323 | 19 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1935576 | 20 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2830657 | 21 CABLE AS (VIDEO, 3-M) | 2 | |
| 2830658 | 22 CABLE AS (VIDEO, 7.5-M) | 1 | |
| 3064129 | 23 STRAP AS | 1 | |
| 3634344 | TERMINAL-RING | 2 | |
| 3524202 | 26 STRAP-CABLE | 2 | |
| 3524204 | 27 STRAP-CABLE | 2 | |
| 3909638 | 28 CABLE AS | 1 | |
| 1M4986 | TERMINAL-RING (0-GA, 1/2-IN SCREW) | 1 | |
| 9X9120 | BOOT (RED) | 1 | |
| 1598047 | CABLE-ELECTRICAL (0-GA, RED)(562-CM) | ||
| 1P0810 | TAPE-ELECTRICAL | ||
| 3010091 | COVER-TERMINAL (RED) | 1 | |
| 4242347 | 29 PLATE | 4 | |
| 4242352 | 30 PLATE | 10 | |
| 4242353 | 31 PLATE AS | 3 | |
| 4242352 | PLATE | 1 | |
| 4242358 | 32 PLATE | 6 | |
| 4242362 | 33 BRACKET AS | 1 | |
| 4242374 | 34 BRACKET AS | 2 | |
| 4242378 | 35 BRACKET AS | 2 | |
| 4609060 | 37 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4792171 | 38 BOLT AS | 51 | |
| 4792172 | 39 BOLT AS | 6 | |
| 4927231 | 40 HARNESS AS-ENGINE | 1 | |
| 4979499 | 41 HARNESS AS-WIRING (ETHER SOLENOID LOAD) | 1 | |
| 5075267 | 42 PLATE AS | 1 | |
| 1305300 | 43 CLIP | 6 | |
| 1W9589 | 44 NUT (M10X1.5-THD) | 2 | |
| 2042281 | 45 STRAP-CABLE | 31 | |
| 2048000 | 46 MOUNTING-CABLE TIE | 31 | |
| 2310336 | 47 STUD-TAPERLOCK (M10X1.5X70-MM) | 2 | |
| 2884402 | 48 STUD-TAPERLOCK (M10X1.5X60-MM) | 18 | |
| 3445675 | 49 NUT (M10X1.5-THD) | 23 | |
| 3524200 | 50 STRAP-CABLE | 1 | |
| 3537957 | 51 GROMMET | 1 | |
| 3557217 | 52 STUD (M10X1.5X90-MM) | 1 | |
| 8T1887 | 53 CLIP (SLOT) | 1 | |
| 8T1888 | 54 CLIP (TAB) | 1 | |
| 8T4121 | 55 WASHER-HARD (11X21X2.5-MM THK) | 36 | |
| 8T4186 | 56 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4196 | 57 BOLT (M10X1.5X35-MM) | 13 |
