System And Components
391-0182 WIRING GP-TORQUE CONVERTERS/N RTL1-103
Group No: 391-0182
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W5331 | 1 BRACKET | 1 | |
| 1243019 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1258534 | 3 PLATE AS | 1 | |
| 1342252 | 4 SENSOR GP-TEMPERATURE (8-VOLT)(TRANSMISSION OIL) | 1 | |
| 2174590 | 5 BRACKET AS | 1 | |
| 2435821 | 6 BRACKET AS | 1 | |
| 4309455 | 7 SENSOR GP-LIQUID LEVEL (HYDROCARBON)(TRANSMISSION OIL) | 1 | |
| 4548550 | 8 GUARD AS-SENSOR | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4792171 | 9 BOLT AS | 10 | |
| 4792172 | 10 BOLT AS | 1 | |
| 4867734 | 11 HARNESS AS-TRANSMISSION (TORQUE CONVERTER) | 1 | |
| 0329828 | 12 GROMMET | 1 | |
| 0910081 | 13 SPACER (10.5X20X10-MM THK) | 3 | |
| 1305300 | 14 CLIP | 7 | |
| 1997854 | 15 SPACER (11.8X20X45-MM THK) | 1 | |
| 2042281 | 16 STRAP-CABLE | 11 | |
| 2048000 | 17 MOUNTING-CABLE TIE | 9 | |
| 2147568 | 18 SEAL-O-RING | 1 | |
| 2213525 | 19 GROMMET | 3 | |
| 2385081 | 20 SEAL-O-RING | 1 | |
| 2887158 | 21 STUD (M10X1.5X125-MM) | 1 | |
| 3068526 | 22 GROMMET | 2 | |
| 3091905 | 23 STUD-TAPERLOCK (M10X1.5X100-MM) | 1 | |
| 3445675 | 24 NUT (M10X1.5-THD) | 4 | |
| 3557217 | 25 STUD (M10X1.5X90-MM) | 1 | |
| 5S7382 | 26 BOLT (3/8-16X1.375-IN) | 1 | |
| 6V0826 | 27 GROMMET | 2 | |
| 8T1889 | 28 CLIP (SLOT) | 7 | |
| 8T1890 | 29 CLIP (TAB) | 7 | |
| 8T2501 | 30 BOLT (3/8-16X2-IN) | 1 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4137 | 32 BOLT (M10X1.5X20-MM) | 4 |
