301-6847 CORE GP-OIL COOLERS/N D3T1-UP

Group No: 301-6847

Part Number	Part Name	Qty
8N8570	1 RING-RETAINING	1
3557217	2 STUD (M10X1.5X90-MM)	28
1008014	3 BONNET	2
1996683	5 CORE GP-OIL COOLER (STEERING)	1
2443712	PLUG AS	1
9S4191	PLUG (9/16-18-THD)	1
2147568	SEAL-O-RING	1
2876096	6 GASKET	6
2885221	7 RETAINER	2
3001341	8 PLATE AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
3220106	9 PLATE	1
3220385	10 PLATE AS	1
3523105	11 CORE AS-OIL COOLER (BRAKE)	2
4305381	12 CORE AS-OIL COOLER (TRANSMISSION)	1
1364184	BOLT-SOCKET HEAD (M8X1.25X40-MM)	8
2391139	SEAL	2
3393268	13 BONNET	2
3395722	14 BONNET	2
3404262	15 PLATE	1
3404274	16 BRACKET AS	1
3404275	17 BRACKET AS	1
3405657	18 BONNET	1
3405658	19 BONNET	1
3413782	20 BRACKET AS	4
3420670	21 BRACKET AS	1
3420671	22 BRACKET AS	1
2443712	23 PLUG AS	6
9S4191	PLUG (9/16-18-THD)	1
2147568	SEAL-O-RING	1
1984777	24 WASHER-HARD (11X25X10-MM THK)	9
1984778	25 WASHER-HARD (13.5X30X12-MM THK)	62
3J5390	26 PLUG (3/8-18-THD)	4
8T2903	27 SEAL-O-RING	1
8T4121	28 WASHER-HARD (11X21X2.5-MM THK)	121
8T4133	29 NUT (M10X1.5-THD)	30
8T4172	30 BOLT (M10X1.5X80-MM)	12
8T4178	31 BOLT (M10X1.5X90-MM)	9
8T4183	32 BOLT (M12X1.75X40-MM)	8
8T4184	33 BOLT (M12X1.75X45-MM)	4
8T4194	34 BOLT (M12X1.75X50-MM)	10
8T4195	35 BOLT (M10X1.5X30-MM)	4
8T4196	36 BOLT (M10X1.5X35-MM)	2
8T4223	37 WASHER-HARD (13.5X25.5X3-MM THK)	13
8T4244	38 NUT (M12X1.75-THD)	20
8T4910	39 BOLT (M12X1.75X60-MM)	25
8T5005	40 BOLT (M10X1.5X70-MM)	71
8T6466	41 BOLT (M10X1.5X60-MM)	2
8T8919	42 BOLT (1/2-13X1.75-IN)	8
9M8546	43 GASKET	2
