System And Components
506-1946 FORK GP-LOGS/N A781-UP
Group No: 506-1946
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1374234 | 1 PLATE-IDENTIFICATION (WORK TOOL) | 1 | |
| 1533742 | 2 TIP-WEAR | 2 | |
| 1533743 | 3 PIN-RETAINER | 4 | |
| 1533744 | 4 RING-RETAINING | 4 | |
| 1598035 | 5 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 6 FILM-WARNING (READ OMM) | 1 | |
| 1794494 | 7 CAP-PROTECTIVE | 2 | |
| 2032208 | 8 CYLINDER GP-FORK (LOGGING) | 2 | |
| 2533431 | 9 FILM-WARNING (CRUSH HAZARD, FORKS, READ OMM) | 2 | |
| 2V1195 | 10 SPACER-SPECIAL | 4 | |
| 3125694 | 11 SETSCREW (1/4-20X0.25-IN) | 1 | |
| 3B8489 | 12 FITTING-GREASE (1/8-27 PTF) | 4 | |
| 5794563 | 13 FRAME AS | 1 | |
| 3740875 | 14 PIN AS | 2 | |
| 3740876 | 15 PIN AS | 2 | |
| 3740877 | 16 PIN AS | 2 | |
| 3988312 | 18 HOSE AS | 2 | |
| 5K9090 | 19 SEAL-O-RING | 3 | |
| 5061952 | 20 CLAMP AS | 1 | |
| 8K2360 | 20A BUSHING | 4 | |
| 3B8489 | FITTING-GREASE (1/8-27 PTF) | 2 | |
| 7K9209 | SEAL-LIP TYPE | 4 | |
| 1638808 | BOSS-TAPPED (M12X1.75X38-MM) | 2 | |
| 3485816 | 22 HOSE AS | 1 | |
| 3989255 | 23 HOSE AS | 1 | |
| 3D2824 | 24 SEAL-O-RING | 4 | |
| 3E7443 | 25 TEE-UNION | 2 | |
| 4230392 | 26 HOSE AS | 1 | |
| 4235018 | 27 HOSE AS | 1 | |
| 5P7468 | 28 CLIP (SLOT) | 2 | |
| 5P7469 | 29 CLIP (TAB) | 2 | |
| 5P8444 | 30 GROMMET (37-MM ID) | 2 | |
| 6V9004 | 31 ELBOW | 2 | |
| 6V9746 | 32 SEAL-O-RING | 8 | |
| 6V9854 | 33 ELBOW (SWIVEL) | 1 | |
| 7G3832 | 34 GROMMET | 3 | |
| 7G3833 | 35 CLIP (TAB) | 3 | |
| 7G3834 | 36 CLIP (SLOT) | 3 | |
| 7X2562 | 37 BOLT (M20X2.5X45-MM) | 2 | |
| 8C8400 | 38 ELBOW | 2 | |
| 8G6122 | 39 SPACER (23X40X19-MM THK) | 2 | |
| 8T4139 | 40 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4184 | 41 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4194 | 42 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4223 | 43 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4244 | 44 NUT (M12X1.75-THD) | 2 |
