Assembly
100%

569-9680 WIRING GP-COMMUNICATIONS/N HRT1-UP

Group No: 569-9680
Part NumberPart NameQty
09100811 SPACER (10.5X20X10-MM THK)1
12585342 PLATE AS1
8T3490NUT-WELD (M10X1.5-THD)1
13369343 SPACER (11X20X25-MM THK)1
18446454 FUSE (175-AMPERE)1
35572175 STUD (M10X1.5X90-MM)4
13275516 SPACER (11X19X6-MM THK)1
20422817 STRAP-CABLE13
22454458 STUD-TAPERLOCK (M10X1.5X75-MM)1
25971409 STUD-TAPERLOCK (M10X1.5X80-MM)1
268477910 STUD-TAPERLOCK (M10X1.5X95-MM)4
288715811 STUD (M10X1.5X125-MM)6
309190512 STUD-TAPERLOCK (M10X1.5X100-MM)5
344567513 NUT (M10X1.5-THD)18
479217214 BOLT AS1
569969015 CABLE AS1
3S2093STRAP-CABLE2
9X4519BOOT (RED)1
1598053CABLE-ELECTRICAL (0000-GA, RED)(1216-CM)
3482314TERMINAL AS-RING1
1355010TUBE-HEAT SHRINK (52-MM DIA)(5-CM)
2611730TERMINAL-RING (0000-GA, 1/2-IN SCREW)1
3482317TERMINAL AS-RING1
1355010TUBE-HEAT SHRINK (52-MM DIA)(5-CM)
3L7634TERMINAL-RING (0000-GA, 1/2-IN SCREW)1
3487341COVER-TERMINAL1
2P197416 STUD-TAPERLOCK (3/8-16X4.2-IN)1
5G367617 GROMMET26
6V880118 NUT (3/8-16-THD)1
8T188919 CLIP (SLOT)13
8T189020 CLIP (TAB)13
8T412121 WASHER-HARD (11X21X2.5-MM THK)19
8T418622 BOLT (M10X1.5X40-MM)1
8T419223 BOLT (M12X1.75X25-MM)1
8T419524 BOLT (M10X1.5X30-MM)2
8T422325 WASHER-HARD (13.5X25.5X3-MM THK)1
8T489626 WASHER-HARD (10.2X18.5X2.5-MM THK)3
