System And Components
431-8852 BRAKE GP-PARKINGS/N DM31-UP; SMZ1-UP
Group No: 431-8852
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2L6726 | 1 RING-RETAINING | 1 | |
| 6F6672 | 2 SEAL-O-RING | 1 | |
| 1334292 | 3 SEAL-LIP TYPE | 1 | |
| 1620177 | 4 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 1719375 | 5 SEAL-O-RING | 1 | |
| 1873369 | 6 SPRING | 4 | |
| 1880633 | 7 SEAL-BRAKE | 1 | |
| 2413722 | 8 FILM-WARNING (RECOIL SPRING) | 1 | |
| 2468743 | 9 YOKE AS | 1 | |
| 2H4145 | SEAL-O-RING | 1 | |
| 6V6767 | RING-RETAINING | 1 | |
| 1726423 | CUP-DUST | 1 | |
| 2468777 | 10 SEAL-BRAKE | 1 | |
| 2468780 | 11 PLATE-CLUTCH | 6 | |
| 2972830 | 12 PLATE AS | 1 | |
| 5M7937 | DOWEL | 2 | |
| 3438739 | 13 DISC-FRICTION | 5 | |
| 4318816 | 14 HOUSING AS-BRAKE | 1 | |
| 3810662 | 15 HUB-BRAKE | 1 | |
| 4318842 | 16 PISTON | 1 | |
| 2904134 | 17 VALVE-RELIEF | 1 | |
| 0950930 | 18 RING-RETAINING (EXTERNAL) | 1 | |
| 1293181 | 19 BOLT-SOCKET HEAD (M10X1.5X55-MM) | 3 | |
| 3156094 | 20 DOWEL | 3 | |
| 7X0605 | 21 WASHER-HARD (13X28X1.6-MM THK) | 12 | |
| 8T5092 | 22 BOLT (M12X1.75X150-MM) | 12 | |
| 1U8846 | 23 SEALANT-GASKET |
