System And Components
232-3120 COOLER GP-TRANSMISSION OILS/N TXF1-UP
Group No: 232-3120
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S0795 | 1 GASKET | 2 | |
| 8M9307 | 2 PLUG (TRANSMISSION OIL COOLER) | 1 | |
| 8S4304 | 3 BONNET-XMSN OIL COOLER | 1 | |
| 1245043 | 4 COUPLING | 1 | |
| 1873523 | 5 CORE AS-OIL COOLER (TRANSMISSION) | 1 | |
| 8T6764 | PLUG-PIPE (1/8-27-THD) | 1 | |
| 4517256 | 6 BRACKET | 1 | |
| 3080950 | 7 BRACKET AS | 1 | |
| 3493310 | 8 BONNET (TRANSMISSION OIL COOLER) | 1 | |
| 3535124 | 9 PLUG AS | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 3535144 | 10 PLUG AS | 1 | |
| 6V5064 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 0969986 | 11 BOLT (M12X1.75X55-MM) | 2 | |
| 1712438 | 12 BOLT-12 POINT HEAD (M12X1.75X30-MM) | 6 | |
| 2N5243 | 13 SEAL-O-RING | 2 | |
| 3E4353 | 14 WASHER-HARD (11X25X3-MM THK) | 2 | |
| 3H5523 | 15 COVER | 2 | |
| 3J5553 | 16 GASKET | 2 | |
| 5P8245 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 6F7062 | 18 WASHER (12.7X19.05X1.83-MM THK) | 1 | |
| 6H1717 | 19 BOLT (1/2-13X1.125-IN) | 2 | |
| 6V1820 | 20 BOLT (M10X1.5X30-MM) | 2 | |
| 6V2317 | 21 BOLT (M8X1.25X30-MM) | 2 | |
| 6V3668 | 22 BOLT (M12X1.75X30-MM) | 4 | |
| 6V5219 | 23 BOLT (M8X1.25X40-MM) | 3 | |
| 8T4179 | 24 BOLT (M12X1.75X20-MM) | 8 | |
| 9M1974 | 25 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 6V8675 | 26 BOLT (M12X1.75X35-MM) | 2 | |
| 7D1649 | 27 WASHER-HARD (13.5X32X5-MM THK) | 2 |
