System And Components
365-0074 HOUSING GP-FRONTFOR USE WITH GUARD GP
Group No: 365-0074
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2237852 | 1 SEAL-INTEGRAL | 1 | |
| 2264755 | 2 SEAL GP-CRANKSHAFT | 1 | |
| 2514314 | 3 ADAPTER | 1 | |
| 2572015 | 4 GASKET | 1 | |
| 4394636 | 5 COVER AS | 1 | |
| 3614681 | 6 HOUSING AS-FRONT | 1 | |
| 6V3535 | 6A DOWEL | 2 | |
| 3560955 | 7 GEAR AS-DRIVE | 1 | |
| 5P6727 | BALL BEARING | 1 | |
| 8H9789 | BALL BEARING | 1 | |
| 2219357 | GEAR-AUXILIARY DRIVE (40-TEETH) | 1 | |
| 1178801 | 8 SEAL-O-RING | 1 | |
| 3E8016 | 9 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 1 | |
| 6V2317 | 10 BOLT (M8X1.25X30-MM) | 13 | |
| 6V5192 | 11 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 3 | |
| 6V5219 | 12 BOLT (M8X1.25X40-MM) | 9 | |
| 6V8225 | 13 NUT (M6X1-THD) | 5 | |
| 9M1974 | 14 WASHER-HARD (8.8X16X2-MM THK) | 30 | |
| 9X2099 | 15 STUD (M8X1.25X52.75-MM) | 4 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 5 |
