Assembly
100%

235-1244 MOUNTING GP-ENGINE & GENERATORS/N C4G1-UP

Group No: 235-1244
Part NumberPart NameQty
9W65821 SLEEVE4
9W99302 MOUNT AS2
22863553 BEAM AS1
2332263SPACER-SPECIAL2
23322274 BEAM AS1
2332263SPACER-SPECIAL2
24103885 BRACKET AS1
23512426 BRACKET AS2
23512457 SPACER (22X125X3-MM THK)2
7X25328 BOLT (M20X2.5X130-MM)2
7X25539 BOLT (M16X2X40-MM)6
8C847810 BOLT (M20X2.5X140-MM)2
8T412111 WASHER-HARD (11X21X2.5-MM THK)16
8T412312 WASHER (22X35X3.5-MM THK)6
8T413113 NUT (M20X2.5-THD)4
8T413314 NUT (M10X1.5-THD)8
8T417015 BOLT (M20X2.5X150-MM)2
8T419316 BOLT (M16X2X50-MM)2
8T419517 BOLT (M10X1.5X30-MM)8
9W658418 WASHER (20.5X114X10-MM THK)4
9W993119 MOUNT AS2
9X825720 WASHER (17.5X30X3.5-MM THK)8
241038921 BRACKET AS1
8T424422 NUT (M12X1.75-THD)8
8T422323 WASHER-HARD (13.5X25.5X3-MM THK)16
8T418324 BOLT (M12X1.75X40-MM)8
8T543925 WASHER-HARD (21.5X45X6-MM THK)2
