156-6821 AIR CONDITIONER GPS/N 3GZ1-UP

Group No: 156-6821

Part Number	Part Name	Qty
1P6522	1 GROMMET	1
2S3745	2 SCREW-TAPPING (10-16X0.5-IN)	6
3B4501	3 LOCKWASHER	2
3E1841	4 LEVER	1
3E5464	5 SWITCH AS-THERMOSTAT (HVAC)	1
3S2093	6 STRAP-CABLE	1
5C9553	7 BOLT (M6X1X16-MM)	4
6V1668	8 WASHER (6.5X29.1X3-MM THK)	2
7F2050	9 LOCKNUT (3/4-16-THD)	1
7F2060	10 LOCKNUT (7/8-14-THD)	1
8C4586	11 CLAMP	2
8C8457	12 SCREW-MACHINE (M5X0.8X14-MM)	1
8T0154	13 CLAMP-HOSE	6
8T4171	14 BOLT (M6X1X12-MM)	4
8T4205	15 WASHER-HARD (7.2X14.5X2-MM THK)	13
8T6631	16 SCREW-MACHINE (8-32X0.5-IN)	2
8Y5737	17 CLAMP	1
9G1950	18 RESISTOR	1
9X2044	19 SCREW-TRUSS HEAD (M6X1X16-MM)	1
9X2185	20 SCREW (8-15X0.44-IN)	4
0374426	21 RETAINER	1
1003143	22 PLATE-ORIFICE	2
1003426	23 WHEEL AS-BLOWER	2
0374838	CLAMP	2
1020341	24 CLIP (TAB)	1
1130302	25 COIL AS-HEATER	1
1143140	26 GROMMET	1
1167856	27 KNOB (AIR CONDITIONER)	2
1185044	28 HARNESS AS-WIRING (CAB HEATER)	1
1185046	29 HOUSING AS	1
1248494	30 GASKET	2
1248495	31 VALVE AS-WATER (AIR CONDITIONER)	1
1278613	32 GASKET	1
1293178	33 LOCKNUT (M6X1-THD)	3
1419784	34 BOLT (M6X1X190-MM)	1
1510894	35 COVER AS	1
1566822	36 CASE AS	1
4V0969	PLATE AS	4
1741486	37 MOTOR AS-BLOWER (24-VOLT, A/C, HEATER)	1
9W0852	PIN-CONNECTOR (14-GA TO 16-GA)	2
1028802	KIT-RECEPTACLE (2-PIN)	1
1803528	38 COIL AS-EVAPORATOR	1
1891707	ORIFICE AS-AIR CONDITIONER	1
1807486	39 COVER AS	1
1807487	40 FILTER ELEMENT-CAB AIR (ACTIVATED CHARCOAL)	1
2H3922	41 LOCKWASHER	1
2H3923	42 LOCKWASHER	1
6V7728	43 BOLT (M6X1X45-MM)	1
1361953	44 HOSE (17.8-CM)
1361953	44A HOSE (15.2-CM)
1361953	44B HOSE (22.9-CM)
5P7070	45 INSULATION-STRIP (0.6-M EACH)
5P5908	46 SEAL (0.12-M)
5P5643	47 SEAL (0.4-M)
8T5372	48 SEAL (0.2-M)
8T5372	48A SEAL (0.2-M EACH)
6V1392	49 SEAL (0.6-M)
6V1392	49A SEAL (0.2-M EACH)
