450-9228 LINES GP-AIR CONDITIONERS/N CS81-UP; P681-UP

Group No: 450-9228

Part Number	Part Name	Qty
5P3928	1 COUPLING AS-REFRIGERANT (SELF-SEALING)	1
5P3929	2 COUPLING AS-REFRIGERANT (SELF-SEALING)	1
5P3948	3 COUPLING AS-REFRIGERANT (SELF-SEALING)	1
7K1181	4 STRAP-CABLE	1
7K3176	5 COUPLING AS-REFRIGERANT (SELF-SEALING)	1
1028703	6 PLATE-COVER	1
5258437	7 PLATE-INSTRUCTION (AIR CONDITIONER)	1
1866190	8 ACCUMULATOR GP-REFRIGERANT (CHARGED)	1
3118367	9 PLATE	1
3270282	10 SEAL-INTEGRAL (1/2-IN)	1
3270283	11 SEAL-INTEGRAL (3/4-IN)	1
3553148	12 SWITCH AS-PRESSURE (HIGH, LOW)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
3626754	13 BRACKET AS	1
3629617	14 HOSE AS	1
3630311	15 HOSE AS	1
3630320	16 HOSE AS	1
3630341	17 HOSE AS	1
3630370	18 HOSE AS	1
3630373	19 HOSE AS	1
0673045	20 CLIP (LOOP)	1
1772215	21 STRAP-DUAL CLAMP	4
1783336	22 NUT-HEX FLANGE (M8X1.25-THD)	2
1783620	23 STRAP-DUAL CLAMP	4
2320231	24 CLAMP-HALF	2
2458842	25 CLIP (LOOP)	1
2H3924	26 LOCKWASHER	1
3445674	27 NUT (M8X1.25-THD)	1
3S8664	28 CLIP	1
5P4106	29 NUT (1-7/16-16-THD)	1
5P4107	30 LOCKWASHER	1
5P4116	31 WASHER-HARD (8.8X20.5X2-MM THK)	8
6V4356	32 CLIP (SLOT)	1
6V4357	33 CLIP (TAB)	1
7K3304	34 NUT-JAM (1-20-THD)	1
7X2536	35 BOLT (M8X1.25X14-MM)	1
7X7729	36 WASHER (11X25X3-MM THK)	1
8T4196	37 BOLT (M10X1.5X35-MM)	1
8T6912	38 BOLT (M8X1.25X50-MM)	1
8T7547	39 BOLT (M8X1.25X30-MM)	3
9X7378	40 SEAL-O-RING	1
9X7380	41 SEAL-O-RING	1
9X7381	42 SEAL-O-RING	2
9X7382	43 SEAL-O-RING	1
9X7383	44 SEAL-O-RING	4
9X7384	45 SEAL-O-RING	2
