System And Components
541-9114 LINES GP-FUEL -SUPPLYS/N MLX1-UP
Group No: 541-9114
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E4444 | 1 VALVE | 3 | |
| 2965728 | 2 CONNECTOR-PIPE | 6 | |
| 3631352 | 3 ADAPTER-ELBOW | 3 | |
| 4175131 | 4 PIPE AS | 1 | |
| 4175133 | 5 BRACKET AS | 2 | |
| 5464744 | 6 HOSE AS | 1 | |
| 4893090 | 7 HOSE AS | 1 | |
| 5464745 | 8 HOSE AS | 1 | |
| 5464746 | 9 HOSE AS | 1 | |
| 5224822 | 10 HOSE AS | 1 | |
| 1715338 | 11 PLUG-PIPE | 1 | |
| 1K6872 | 12 LOCKNUT (1/2-13-THD) | 8 | |
| 2287091 | 13 SEAL-O-RING | 1 | |
| 2287092 | 14 SEAL-O-RING | 1 | |
| 2287093 | 15 SEAL-O-RING | 3 | |
| 2287095 | 16 SEAL-O-RING | 6 | |
| 2385081 | 17 SEAL-O-RING | 1 | |
| 2385084 | 18 SEAL-O-RING | 1 | |
| 3706141 | 19 CLIP (SLOT) | 2 | |
| 3706142 | 20 CLIP (TAB) | 2 | |
| 3706219 | 21 GROMMET | 2 | |
| 3M7045 | 22 PLUG (3/4-14 NPT-THD) | 1 | |
| 4B8586 | 23 PLUG-PIPE | 2 | |
| 5P1076 | 24 WASHER-HARD (13.5X30X4-MM THK) | 16 | |
| 5P7468 | 25 CLIP (SLOT) | 3 | |
| 5P7469 | 26 CLIP (TAB) | 3 | |
| 6V4349 | 27 GROMMET | 2 | |
| 6V5729 | 28 LOCKNUT (7/16-14-THD) | 7 | |
| 6V8635 | 29 CONNECTOR | 1 | |
| 6V9854 | 30 ELBOW (SWIVEL) | 1 | |
| 7B7138 | 31 ELBOW | 1 | |
| 7X0589 | 32 WASHER-HARD (12X28.5X5-MM THK) | 2 | |
| 8C6875 | 33 CONNECTOR | 1 | |
| 8C6877 | 34 BOLT (7/16-14X1.75-IN) | 2 | |
| 8D0482 | 35 GROMMET | 1 | |
| 8T5360 | 36 WASHER (12X22.5X2.5-MM THK) | 12 | |
| 8T5389 | 37 ELBOW | 1 | |
| 8T7087 | 38 GROMMET (34-MM ID) | 1 | |
| 8T8916 | 39 BOLT (7/16-14X1.5-IN) | 5 | |
| 8T8919 | 40 BOLT (1/2-13X1.75-IN) | 8 |
