System And Components
487-0238 PUMP GP-PRELUBRICATIONAN ATTACHMENT
Group No: 487-0238
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2960014 | 1 PUMP GP-PRELUBRICATION (24-VOLT) | 1 | |
| 3132647 | 2 VALVE-BALL | 1 | |
| 3139605 | 3 ELBOW | 1 | |
| 3139606 | 4 ELBOW | 2 | |
| 3154832 | 5 BRACKET | 1 | |
| 3410113 | 6 ELBOW AS | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 2287108 | SEAL-O-RING | 1 | |
| 3410112 | ADAPTER-ELBOW | 1 | |
| 3488729 | 7 VALVE-CHECK | 1 | |
| 3788929 | 8 HOSE AS | 1 | |
| 5251831 | 9 HOSE AS | 1 | |
| 1343196 | 10 WASHER (10.2X39.6X2.3-MM THK) | 8 | |
| 1682067 | 11 MOUNT AS | 4 | |
| 1F7854 | 12 SPACER (11.01X19.05X49.21-MM THK) | 1 | |
| 2270066 | 13 CONNECTOR | 1 | |
| 2287094 | 14 SEAL-O-RING | 2 | |
| 2287096 | 15 SEAL-O-RING | 3 | |
| 2287108 | 16 SEAL-O-RING | 2 | |
| 3445675 | 17 NUT (M10X1.5-THD) | 5 | |
| 3474445 | 18 ADAPTER | 1 | |
| 5P5846 | 19 SEAL-O-RING | 1 | |
| 5P7470 | 20 CLIP (SLOT) | 1 | |
| 5P7471 | 21 CLIP (TAB) | 1 | |
| 5P8182 | 22 GROMMET (46-MM ID) | 1 | |
| 6V5100 | 23 SEAL-O-RING | 2 | |
| 6V8400 | 24 SEAL-O-RING | 1 | |
| 6V9006 | 25 ELBOW | 1 | |
| 8T3647 | 26 BOLT (M8X1.25X80-MM) | 4 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4178 | 29 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4182 | 30 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4186 | 31 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4224 | 32 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4908 | 33 BOLT (M8X1.25X25-MM) | 4 | |
| 8T5005 | 34 BOLT (M10X1.5X70-MM) | 4 |
