System And Components
364-4185 BOX GP-CONTROL -INTERFACE (CHG -01)AN ATTACHMENT
Group No: 364-4185
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1471960 | 1 RAIL | 2 | |
| 1558755 | 2 FUSE (10-AMPERE) | 2 | |
| 1735413 | 3 CLAMP | 2 | |
| 2059470 | 4 MOUNT-FLEXIBLE | 6 | |
| 2064012 | 5 RELAY (24-VOLT, 40-AMPERE)(GENERATOR SPACE HEATER) | 1 | |
| 2110640 | 6 SPRING (RELAY) | 1 | |
| 2236470 | 7 RELAY (10-AMPERE, 24-VOLT)(AUXILIARY) | 1 | |
| 2250907 | 8 BRIDGE (3-POSITION) | 2 | |
| 2521731 | 9 MODULE-DIODE | 1 | |
| 2521732 | 10 BASE-RELAY | 1 | |
| 3149098 | 11 BLOCK-TERMINAL (600-VOLT, 25-AMPERE) | 25 | |
| 3149099 | 12 COVER-TERMINAL | 10 | |
| 3149100 | 13 BAR-FIXED BRIDGE | 2 | |
| 3149101 | 14 BRACKET-END | 2 | |
| 3212524 | 15 BLOCK-TERMINAL (300-VOLT, 15-AMPERE) | 2 | |
| 3387198 | 16 TERMINAL | 6 | |
| 3387214 | 17 KIT-MARKER | 1 | |
| 3387216 | 18 BRACKET | 1 | |
| 3387225 | 19 COVER-END | 3 | |
| 3466814 | 20 BRIDGE | 3 | |
| 3521442 | 21 MODULE AS-CONTROL | 1 | |
| 3616925 | 22 PLATE AS | 1 | |
| 3616927 | 23 HARNESS AS-POWER (INTERFACE) | 1 | |
| 3616934 | 25 TRANSFORMER | 1 | |
| 3644186 | 26 HARNESS AS-BOX | 1 | |
| 3644187 | 27 HARNESS AS-BOX | 1 | |
| 3663460 | 28 FILM-CIRCUIT | 1 | |
| 3663461 | 29 KIT-MARKER | 1 | |
| 3663463 | 30 STRIP GP-TERMINAL | 1 | |
| 3663464 | 31 BOX GP-CONTROL | 1 | |
| 3663467 | 32 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 7 | |
| 0950723 | 33 SCREW-SPECIAL (M3X0.5X10-MM) | 4 | |
| 1514977 | 34 WASHER (4.445X9.525X1.092-MM THK) | 56 | |
| 1924658 | 35 SCREW-PAN HEAD (M4X0.7X20-MM) | 2 | |
| 2046102 | 36 WASHER-HARD (4.45X9.52X1-MM THK) | 2 | |
| 2643613 | 37 WASHER (3.7X7X.5-MM THK) | 4 | |
| 3C6969 | 38 NUT (M3X0.5-THD) | 4 | |
| 4B4863 | 39 WASHER (4.7X11X1.2-MM THK) | 8 | |
| 5C2890 | 40 NUT (M6X1-THD) | 2 | |
| 5P9135 | 41 GROMMET | 1 | |
| 6S8584 | 42 SCREW (M4X0.7-THD) | 28 | |
| 6V5683 | 43 BOLT (M6X1X16-MM) | 4 | |
| 8C7508 | 44 LOCKWASHER | 12 | |
| 8T0337 | 45 SCREW-MACHINE (M4X0.7X12-MM) | 8 | |
| 8T2659 | 46 LOCKNUT (M4X0.7-THD) | 28 | |
| 8T4121 | 47 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 8T4137 | 48 BOLT (M10X1.5X20-MM) | 11 | |
| 8T4138 | 49 BOLT (M6X1X20-MM) | 2 | |
| 8T8442 | 50 BOLT-SOCKET HEAD (M6X1X30-MM) | 4 | |
| 9X8256 | 51 WASHER (6.6X12X2-MM THK) | 8 | |
| 1666159 | 52 DUCT-WIRE | 9 |
