473-7582 ENCLOSURE GPS/N DX9147-UP

Group No: 473-7582

Part Number	Part Name	Qty
9X2092	1 TRIM-EDGE (44-CM)
7K3262	2 SCREW	2
2822270	3 STRAINER-FUEL (TANK)	1
3233309	4 CAP	2
3455867	5 INSULATION	2
4375042	6 COVER	1
4449532	7 PLATE (BOOT)	4
4449533	8 PLATE (BOOT)	4
4449680	9 GROMMET	2
4586064	10 BOOT AS	2
4937965	11 PLATE AS (LH)	1
7K4201	NUT-SPEED	2
9R2821	BOSS (M10X1.5X15-MM)	2
0337291	RIVET-POP	4
4625998	12 PLATE AS (RH)	1
4625999	13 PLATE AS (LH)	1
1599540	NUT-WELD (M8X1.25-THD)	1
4626592	14 GASKET	1
4626593	15 PLATE	1
4626594	16 PLATE	2
4626673	17 COVER AS	1
4719967	18 SUPPORT AS (RH)	1
4719968	19 SUPPORT AS (LH)	1
1403943	STUD (M6X1X16-MM)	8
1599539	NUT-WELD (M6X1-THD)	4
4739356	20 GASKET	1
4739357	21 PLATE	1
4739358	22 PLATE AS	1
3E6908	STUD-WELD (M8X1.25X20-MM)	3
4767386	23 SUPPORT AS (LH)	1
4767387	24 SUPPORT AS (RH)	1
1599539	NUT-WELD (M6X1-THD)	7
4767388	25 BRACKET (LH)	1
4767389	26 BRACKET (RH)	1
5061746	27 PLATE	2
4937966	28 COVER AS	1
1138694	29 BOLT (M6X1X20-MM)	23
1749194	30 BOLT (M8X1.25X16-MM)	2
2663314	31 BOLT-FLANGE HEAD (M6X1X20.5-MM)	6
2663316	32 BOLT-FLANGE HEAD (M10X1.5X25-MM)	2
3429922	33 BOLT-FLANGE HEAD (M8X1.25X25-MM)	2
3434072	34 BOLT-FLANGE HEAD (M6X1X25-MM)	10
5C7261	35 NUT (M8X1.25-THD)	2
5H9743	36 GROMMET	1
5P4116	37 WASHER-HARD (8.8X20.5X2-MM THK)	9
6V7743	38 LOCKNUT (M6X1-THD)	16
6V9189	39 LOCKNUT (M8X1.25-THD)	3
7X2031	40 RETAINER	2
8T4121	41 WASHER-HARD (11X21X2.5-MM THK)	1
8T4136	42 BOLT (M10X1.5X25-MM)	1
8T4183	43 BOLT (M12X1.75X40-MM)	2
8T4205	44 WASHER-HARD (7.2X14.5X2-MM THK)	16
8T4223	45 WASHER-HARD (13.5X25.5X3-MM THK)	2
8T6726	46 CLAMP-HOSE	2
9X2038	47 WASHER (7X19X2-MM THK)	6
1328502	48 SEAL (71-CM EACH)
1328502	48A SEAL (52.2-CM)
1328502	48B SEAL (18-CM)
1328502	48C SEAL (17-CM)
1233827	49 SEAL (118.5-CM)
1233827	49A SEAL (15-CM EACH)
1233827	49B SEAL (79.5-CM EACH)
