System And Components
462-6958 TANK GP-FUELS/N H221-UP
Group No: 462-6958
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4667023 | 1 STRAP AS | 1 | |
| 1803730 | 2 STRAINER-FUEL (FILLER NECK SCREEN) | 1 | |
| 4223634 | 3 NUT-INSERT (M10X1.5-THD) | 3 | |
| 4637939 | 4 BRACKET | 1 | |
| 4637940 | 5 PLATE | 1 | |
| 4637953 | 6 BRACKET AS | 1 | |
| 4683865 | 7 FLOAT (FUEL LEVEL) | 1 | |
| 4683878 | 8 FUEL PICKUP AS | 1 | |
| 5159676 | STRAINER AS (FUEL TANK) | 1 | |
| 4804868 | GASKET | 1 | |
| 4727821 | 9 TANK GP-FUEL | 1 | |
| 2064441 | ADAPTER-FUEL CAP | 1 | |
| 2849039 | CAP-FUEL (VENTED) | 1 | |
| 1616984 | 10 SCREW-TRUSS HEAD (M5X0.8X20-MM) | 11 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4196 | 13 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4222 | 14 WASHER-PLATED (11X32X2.5-MM THK) | 2 | |
| 8T4182 | 15 BOLT (M10X1.5X45-MM) | 1 |
