System And Components
315-4827 PUMP GP-PRELUBRICATION -AIRAN ATTACHMENT
Group No: 315-4827
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1090642 | 1 BRACKET | 1 | |
| 1605083 | 2 CONNECTOR | 2 | |
| 1682067 | 3 MOUNT AS | 4 | |
| 2971148 | 4 BRACKET AS | 1 | |
| 2971149 | 5 BRACKET AS | 2 | |
| 3132647 | 6 VALVE-BALL | 1 | |
| 3139605 | 7 ELBOW | 1 | |
| 3139606 | 8 ELBOW | 2 | |
| 3139610 | 9 BRACKET AS | 2 | |
| 3139611 | 10 TUBE AS | 1 | |
| 3139616 | 11 BRACKET AS | 1 | |
| 4433128 | 12 SILENCER-EXHAUST | 1 | |
| 3139618 | 13 LUBRICATOR GP-AIR MOTOR | 1 | |
| 3788929 | 14 HOSE AS | 1 | |
| 3154832 | 15 BRACKET | 1 | |
| 3410113 | 16 ELBOW AS | 1 | |
| 9M4136 | 17 SPACER (0.438X0.75X0.5-IN THK) | 1 | |
| 3159831 | 18 ELBOW | 1 | |
| 3183164 | 19 VALVE GP-SOLENOID (PRELUBRICATION PUMP) | 1 | |
| 3183168 | 20 BRACKET AS | 1 | |
| 5251831 | 21 HOSE AS | 1 | |
| 3239993 | 22 ADAPTER | 2 | |
| 3240018 | 23 HOSE AS | 1 | |
| 3474445 | 24 ADAPTER | 1 | |
| 3488729 | 25 VALVE-CHECK | 1 | |
| 3539825 | 26 PUMP GP-PRELUBRICATION | 1 | |
| 8T4186 | 27 BOLT (M10X1.5X40-MM) | 2 | |
| 1343196 | 28 WASHER (10.2X39.6X2.3-MM THK) | 8 | |
| 1S0994 | 29 CLIP (LOOP) | 1 | |
| 2270056 | 30 ELBOW | 1 | |
| 2270066 | 31 CONNECTOR | 1 | |
| 2287091 | 32 SEAL-O-RING | 5 | |
| 6V8400 | 33 SEAL-O-RING | 1 | |
| 2287094 | 34 SEAL-O-RING | 2 | |
| 2287096 | 35 SEAL-O-RING | 3 | |
| 2287103 | 36 SEAL-O-RING | 3 | |
| 2287108 | 37 SEAL-O-RING | 2 | |
| 5P8182 | 38 GROMMET (46-MM ID) | 1 | |
| 2385080 | 39 SEAL-O-RING | 2 | |
| 8T4133 | 40 NUT (M10X1.5-THD) | 5 | |
| 7X7729 | 41 WASHER (11X25X3-MM THK) | 1 | |
| 5P5846 | 42 SEAL-O-RING | 1 | |
| 5P7471 | 43 CLIP (TAB) | 1 | |
| 5P7470 | 44 CLIP (SLOT) | 1 | |
| 5C7261 | 45 NUT (M8X1.25-THD) | 4 | |
| 8T4223 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 8T4195 | 48 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 49 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4908 | 50 BOLT (M8X1.25X25-MM) | 4 | |
| 8T4136 | 51 BOLT (M10X1.5X25-MM) | 3 | |
| 6V5100 | 52 SEAL-O-RING | 2 | |
| 7X2537 | 53 BOLT (M8X1.25X35-MM) | 4 | |
| 8T3647 | 54 BOLT (M8X1.25X80-MM) | 4 | |
| 8T4184 | 55 BOLT (M12X1.75X45-MM) | 7 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4182 | 58 BOLT (M10X1.5X45-MM) | 1 | |
| 8T5005 | 59 BOLT (M10X1.5X70-MM) | 4 | |
| 8T4244 | 60 NUT (M12X1.75-THD) | 7 | |
| 8T4956 | 61 BOLT (M12X1.75X35-MM) | 4 | |
| 6V9006 | 62 ELBOW | 1 | |
| 6V9170 | 63 NUT-BULKHEAD (1-14-THD) | 4 | |
| 6V9831 | 64 CAP (ORFS) | 1 | |
| 5P1076 | 66 WASHER-HARD (13.5X30X4-MM THK) | 11 | |
| 8T4224 | 67 WASHER-HARD (8.8X16X2-MM THK) | 16 |
