System And Components
461-1901 WIRING GP-CHASSISS/N PRB1-UP
Group No: 461-1901
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 84 | |
| 1220450 | 2 GROMMET | 2 | |
| 1325789 | 3 CLIP (LADDER) | 1 | |
| 1393205 | 4 HARNESS AS-BRAKE | 1 | |
| 1598544 | 5 PLATE AS | 1 | |
| 8D3508 | BOSS (3/8-16X1-IN) | 2 | |
| 7T1099 | LINK | 4 | |
| 9X2092 | TRIM-EDGE (30-CM) | ||
| 2418488 | 6 PLATE | 3 | |
| 3523970 | 7 CLIP (LADDER) | 2 | |
| 3927193 | 8 HARNESS AS-TRANSMISSION | 1 | |
| 6I4348 | BOOT (40-PIN) | 2 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 35 | |
| 9X0141 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 9X3490 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 8T8737 | PLUG-SEAL | 10 | |
| 9X1343 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 35 | |
| 3E5239 | 9 RELAY AS (24-VOLT)(FUEL PRIMING) | 1 | |
| 4611923 | 10 PLATE AS | 1 | |
| 4611970 | 11 HARNESS AS-CHASSIS | 1 | |
| 4611980 | 12 HARNESS AS-FRONT CHASSIS | 1 | |
| 4612040 | 13 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3851 | BOSS-WELD (M10X1.5X17.5-MM) | 1 | |
| 4L6454 | 14 BOLT (3/8-16X1-IN) | 4 | |
| 4P7428 | 15 CLIP (LADDER) | 1 | |
| 4P7581 | 16 CLIP (LADDER) | 65 | |
| 4P8134 | 17 CLIP (LADDER) | 6 | |
| 5M3062 | 18 BOLT (3/8-16X0.75-IN) | 11 | |
| 5S7349 | 19 BOLT (1/4-20X0.5-IN) | 1 | |
| 5S7379 | 20 BOLT (3/8-16X0.875-IN) | 30 | |
| 8T1897 | 21 CLIP (SLOT) | 2 | |
| 8T1898 | 22 CLIP (TAB) | 2 | |
| 8T4121 | 23 WASHER-HARD (11X21X2.5-MM THK) | 52 | |
| 8T4136 | 24 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 25 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4171 | 26 BOLT (M6X1X12-MM) | 1 | |
| 8T4182 | 27 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4196 | 28 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4205 | 29 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 9C5344 | 30 SPACER (10.5X20X18-MM THK) | 1 | |
| 9X8256 | 31 WASHER (6.6X12X2-MM THK) | 1 |
