System And Components
463-0337 LINES GP-FUEL INJECTIONAN ATTACHMENT
Group No: 463-0337
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W2925 | 1 TUBE AS | 1 | |
| 2W0598 | 2 TUBE AS | 1 | |
| 4P0692 | 3 CLAMP AS | 12 | |
| 1081434 | GROMMET | 1 | |
| 4P0693 | 4 CLAMP AS | 6 | |
| 1081434 | GROMMET | 2 | |
| 4P3485 | 5 BRACKET | 1 | |
| 4W1807 | 6 ELBOW-FLARED | 1 | |
| 7C7682 | 7 ADAPTER-FUEL MANIFOLD (RH) | 1 | |
| 7C7683 | 8 ADAPTER-FUEL MANIFOLD (LH) | 1 | |
| 9N4053 | 9 SPRING | 1 | |
| 1125992 | 10 TUBE AS | 1 | |
| 1145477 | 11 PLUNGER-VALVE | 1 | |
| 2176995 | 12 SPACER (12.5X17.14X106-MM THK) | 1 | |
| 3095130 | 13 PLUG AS | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3535133 | 14 ELBOW AS | 3 | |
| 0307949 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3541311 | 15 TUBE AS | 1 | |
| 3650576 | 16 CONNECTOR AS | 2 | |
| 9M4584 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4201795 | 17 VALVE GP-CHECK (FUEL) | 1 | |
| 4623365 | 18 TUBE AS | 1 | |
| 4623366 | 19 TUBE AS | 1 | |
| 4623369 | 20 TUBE AS | 1 | |
| 0038581 | 21 TEE-UNION | 1 | |
| 0307972 | 22 ELBOW | 1 | |
| 0618248 | 23 UNION-FLARED | 1 | |
| 0L1143 | 24 BOLT (3/8-16X2.5-IN) | 1 | |
| 0L2070 | 25 BOLT (3/8-16X2.25-IN) | 3 | |
| 0S1590 | 26 BOLT (3/8-16X2-IN) | 2 | |
| 1D4539 | 27 BOLT (5/16-18X2.5-IN) | 1 | |
| 1D4541 | 28 BOLT (5/16-18X3-IN) | 1 | |
| 2287091 | 29 SEAL-O-RING | 1 | |
| 2385081 | 30 SEAL-O-RING | 1 | |
| 2815984 | 31 ELBOW AS | 1 | |
| 8T5389 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3510258 | 32 ELBOW AS | 1 | |
| 1P7625 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5B2638 | 33 BOLT (3/8-16X5.25-IN) | 1 | |
| 5F4899 | 34 BOLT (3/8-16X5.5-IN) | 1 | |
| 5M2894 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 5P3166 | 36 TEE-SWIVEL | 1 | |
| 7K3377 | 37 PIPE | 2 | |
| 8F8544 | 38 BOLT (3/8-16X6.25-IN) | 1 | |
| 8K2396 | 39 ELBOW-FLARED | 1 | |
| 8M9124 | 40 WASHER (10X22.5X8-MM THK) | 1 | |
| 9M1974 | 41 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S8752 | 42 NUT-FULL (3/8-16-THD) | 2 |
