Assembly
100%

257-0384 STABILIZER GPS/N FB31-UP

Group No: 257-0384
Part NumberPart NameQty
5W28171 FITTING-GREASE10
09303492 WASHER (22X60X6-MM THK)4
11139993 PIN AS2
11140634 PIN AS2
12272526 PLATE-SPRING26
19647607 PAD AS2
36706179 ARM & BEARING AS2
43604409A BEARING2
2586336ARM AS1
258635810 PIN AS2
258636011 TUBE2
313930412 COVER AS2
258639113 PIN AS2
258639214 PIN AS2
258639615 PIN (LH)1
258755416 PIN (RH)1
128838917 PLATE2
8T420019 BOLT (M8X1.25X16-MM)4
8T412320 WASHER (22X35X3.5-MM THK)4
302774621 PLATE2
8T413922 BOLT (M12X1.75X30-MM)4
8T417423 BOLT (M16X2X120-MM)2
8T422324 WASHER-HARD (13.5X25.5X3-MM THK)4
8T422425 WASHER-HARD (8.8X16X2-MM THK)4
8T478027 BOLT (M20X2.5X30-MM)4
8T546028 BOLT (M20X2.5X40-MM)2
