Assembly
100%

260-3448 STABILIZER GP -2-POINTS/N FB31-UP

Group No: 260-3448
Part NumberPart NameQty
5W28171 FITTING-GREASE10
09303492 WASHER (22X60X6-MM THK)4
11140633 PIN AS2
12272524 PLATE-SPRING26
13527855 PIN AS2
19647607 PAD AS2
21957579 BOSS2
313930410 COVER AS2
258639111 PIN AS2
258639212 PIN AS2
367061813 ARM & BEARING AS2
436044113A BEARING2
2603502ARM AS-STABILIZER1
264547314 PIN AS2
264547515 PIN (LH)1
264570416 PIN (RH)1
128838917 PLATE2
8T420019 BOLT (M8X1.25X16-MM)4
7X247520 BOLT (M16X2X130-MM)2
8T412321 WASHER (22X35X3.5-MM THK)4
302774622 PLATE2
8T413923 BOLT (M12X1.75X30-MM)4
8T422324 WASHER-HARD (13.5X25.5X3-MM THK)4
8T422425 WASHER-HARD (8.8X16X2-MM THK)4
8T478027 BOLT (M20X2.5X30-MM)4
8T546028 BOLT (M20X2.5X40-MM)2
