394-8497 BOX GP-CONTROLPART OF 354-2816 BOX & MOUNTING GP

Group No: 394-8497
Part NumberPart NameQty
1S23421 STRAP AS-GROUND1
3E52392 RELAY AS (24-VOLT)(KEY SWITCH PRIMARY)1
3E52392A RELAY AS (24-VOLT)(KEY SWITCH SECONDARY)1
3E52392B RELAY AS (24-VOLT)(POWER MODING)1
3E52392C RELAY AS (24-VOLT)(MANUAL CRANK OVERRIDE 2)1
3E52392D RELAY AS (24-VOLT)(MANUAL CRANK OVERRIDE 1)1
7K11813 STRAP-CABLE40
8C31184 ADAPTER-ELBOW2
9G51275 BREATHER AS (ATMOSPHERIC)(ATMOSPHERIC)2
23308917 BRACKET AS4
2321693BOLT-FLANGE HEAD (M6X1X35-MM)1
26364778 COVER1
26364789 SEAL1
263656610 PLATE2
396458511 MODULE AS-EXHAUST TEMPERATURE1
3434631MODULE-EXHAUST TEMPERATURE (SCANNER)1
307868612 PLUG-BUTTON2
307873413 BOX GP-CONTROL1
318727414 DIODE GP1
349737415 SENSOR GP-PRESSURE (ATMOSPHERIC, SECONDARY)1
349737415A SENSOR GP-PRESSURE (ATMOSPHERIC, PRIMARY)1
354280616 HARNESS AS-BOX1
354280717 HARNESS AS-BOX1
355960718 FILM-IDENTIFICATION (PANEL)1
391304419 CONTROL & MTG GP-ENGINE ELEK2
095064120 BOLT-SOCKET HEAD (M4X0.7X10-MM)5
6V564521 SCREW-MACHINE (10-32X0.87-IN)3
124734622 LOCKWASHER2
130530023 CLIP4
1H439324 LOCKWASHER5
3B450425 LOCKWASHER4
4B427626 WASHER (7X16X1.6-MM THK)1
8F143427 LOCKWASHER3
8T026928 BOLT-SOCKET HEAD (M6X1X20-MM)20
8T412129 WASHER-HARD (11X21X2.5-MM THK)4
8T413330 NUT (M10X1.5-THD)1
8T413731 BOLT (M10X1.5X20-MM)3
8T413832 BOLT (M6X1X20-MM)4
8T417133 BOLT (M6X1X12-MM)1
8T422434 WASHER-HARD (8.8X16X2-MM THK)4
8T490835 BOLT (M8X1.25X25-MM)4
292265436 SLEEVE (31-CM)
292265436A SLEEVE (38-CM EACH)
292265436B SLEEVE (20-CM)
