System And Components
519-8043 BOX GP-CONTROL (CHG -00, -01)PART OF 519-8042 BOX & MOUNTING GP
Group No: 519-8043
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S2342 | 1 STRAP AS-GROUND | 1 | |
| 3E5239 | 2 RELAY AS (24-VOLT) | 5 | |
| 6V2693 | 3 WASHER | 2 | |
| 7K1181 | 4 STRAP-CABLE | 40 | |
| 8C3118 | 5 ADAPTER-ELBOW | 1 | |
| 9G5127 | 6 BREATHER (ATMOSPHERIC) | 1 | |
| 2330891 | 7 BRACKET AS | 4 | |
| 2341644 | 8 CONTROL GP-ENGINE MONITORING (THERMOCOUPLE) | 1 | |
| 2636566 | 9 PLATE | 2 | |
| 3078686 | 10 PLUG-BUTTON | 2 | |
| 3392958 | 11 GASKET | 1 | |
| 3497374 | 12 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3559607 | 13 FILM-IDENTIFICATION (PANEL) | 1 | |
| 4934304 | 14 HARNESS AS-BOX (THERMOCOUPLE) | 1 | |
| 4934307 | 15 BOX GP-CONTROL PANEL | 1 | |
| 5198044 | 16 CONTROL & MTG GP-ENGINE ELEK | 2 | |
| 5198045 | 17 HARNESS AS-BOX (CROSSOVER) | 1 | |
| 1091393 | 18 BOLT-SOCKET HEAD (M4X0.7X10-MM) | 5 | |
| 1533568 | 19 BOLT-SOCKET HEAD (M5X0.8X10-MM) | 4 | |
| 1247346 | 20 LOCKWASHER | 2 | |
| 1305300 | 21 CLIP | 5 | |
| 1H4393 | 22 LOCKWASHER | 5 | |
| 2609153 | 23 PLUG (M10X1-THD) | 1 | |
| 2Y5829 | 24 NUT (M10X1.5-THD) | 1 | |
| 3420606 | 25 WASHER-HARD (5.5X11X1.6-MM THK) | 4 | |
| 3B4504 | 26 LOCKWASHER | 4 | |
| 4B4276 | 27 WASHER (7X16X1.6-MM THK) | 1 | |
| 6V2694 | 28 WASHER (42X51X2-MM THK) | 1 | |
| 6V5683 | 29 BOLT (M6X1X16-MM) | 2 | |
| 6V5839 | 30 WASHER (11X21X2.5-MM THK) | 1 | |
| 8T0269 | 31 BOLT-SOCKET HEAD (M6X1X20-MM) | 20 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 33 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4138 | 34 BOLT (M6X1X20-MM) | 8 | |
| 8T4171 | 35 BOLT (M6X1X12-MM) | 1 | |
| 9X8256 | 36 WASHER (6.6X12X2-MM THK) | 6 | |
| 2922654 | 37 SLEEVE (179-CM) |
