System And Components
352-7832 BELT TENSIONER GPS/N BDN1-2297
Group No: 352-7832
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2061346 | 1 STRAP-CABLE | 1 | |
| 2432310 | 2 COVER | 3 | |
| 3331207 | 3 IDLER AS | 2 | |
| 3458398 | 4 BRACKET-SUPPORT | 1 | |
| 3458399 | 5 BRACKET-SUPPORT | 1 | |
| 3477963 | 6 TENSIONER-BELT | 1 | |
| 2792589 | 7 PULLEY AS-IDLER (8-GROOVE) | 1 | |
| 4306032 | 8 BRACKET-SUPPORT | 1 | |
| 0L1143 | 9 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1352 | 10 BOLT (3/8-16X3.25-IN) | 1 | |
| 0S1571 | 11 BOLT (3/8-16X1.75-IN) | 3 | |
| 4P0983 | 13 STUD (3/8-16-THD) | 1 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 6L4428 | 15 STUD-TAPERLOCK (3/8-16X4.01-IN) | 2 | |
| 6V5839 | 16 WASHER (11X21X2.5-MM THK) | 1 | |
| 8T0643 | 17 BOLT (M10X1.5X80-MM) | 1 | |
| 9S8752 | 18 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 19 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
