System And Components
468-4349 LINES GP-FUELS/N HRZ1-507
Group No: 468-4349
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P7466 | 1 CLIP (SLOT) | 1 | |
| 5P7467 | 2 CLIP (TAB) | 1 | |
| 8W5161 | 3 MANIFOLD | 1 | |
| 1632426 | 4 VALVE-CHECK | 1 | |
| 2451791 | 5 HOSE AS-AIR | 1 | |
| 3211326 | 6 BASE AS-FILTER | 3 | |
| 3232268 | STUD-HOLLOW | 1 | |
| 3574574 | 7 ADAPTER AS | 1 | |
| 8D8428 | ADAPTER | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3893721 | 8 ADAPTER AS | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 2015551 | ADAPTER | 1 | |
| 4323700 | 9 CLAMP | 1 | |
| 4328127 | 10 BUSHING-PIPE | 1 | |
| 4329428 | 11 CLAMP AS | 7 | |
| 8T9101 | BOLT (3/8-16X2.75-IN) | 2 | |
| 4345618 | NUT-SPECIAL | 2 | |
| 4329904 | 12 CLAMP AS | 7 | |
| 4329905 | 13 CLAMP AS | 2 | |
| 5S7383 | BOLT (3/8-16X1.75-IN) | 2 | |
| 4345618 | NUT-SPECIAL | 2 | |
| 4385386 | 14 FILTER AS-WATER SEP & FUEL (ULTRA HIGH EFFICIENCY) | 3 | |
| 4790856 | FILTER AS-WATER SEP & FUEL (ULTRA HIGH EFFICIENCY) | 3 | |
| 4423306 | 15 PIPE AS | 1 | |
| 1P5598 | FITTING | 1 | |
| 4423311 | 16 ADAPTER | 1 | |
| 4423312 | 17 ADAPTER | 1 | |
| 4423313 | 18 HOSE AS | 1 | |
| 4423315 | 19 HOSE AS | 1 | |
| 4684351 | 20 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4687941 | 21 BRACKET AS | 2 | |
| 4792171 | 22 BOLT AS | 13 | |
| 5115018 | 23 PUMP GP-FUEL | 1 | |
| 1358573 | 24 BOLT AS | 4 | |
| 1488317 | 25 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8714 | CONNECTOR | 1 | |
| 1488373 | 26 ELBOW AS | 2 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8C3364 | ELBOW | 1 | |
| 1594724 | 27 VALVE-BALL | 1 | |
| 1644058 | 28 REDUCER AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8948 | REDUCER | 1 | |
| 1858834 | 29 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1314863 | ELBOW | 1 | |
| 1P5598 | 30 FITTING | 1 | |
| 2147568 | 31 SEAL-O-RING | 1 | |
| 2256948 | 32 SEAL-O-RING | 6 | |
| 2307636 | 33 HOSE AS | 1 | |
| 3293356 | 34 NUT (M12X1.75-THD) | 1 | |
| 3445675 | 35 NUT (M10X1.5-THD) | 3 | |
| 3B6499 | 36 ELBOW | 1 | |
| 3J1907 | 37 SEAL-O-RING | 2 | |
| 4264093 | 38 ADAPTER AS | 2 | |
| 2385084 | SEAL-O-RING | 1 | |
| 4264092 | ADAPTER-TEE | 1 | |
| 4423320 | 39 VALVE | 1 | |
| 4423321 | 40 CLAMP AS | 1 | |
| 4507321 | 41 HOSE AS | 1 | |
| 4779134 | 42 HOSE AS | 1 | |
| 4S4455 | 43 CLIP | 2 | |
| 5689487 | 44 HOSE AS | 1 | |
| 5M3062 | 45 BOLT (3/8-16X0.75-IN) | 2 | |
| 5P7701 | 46 SEAL-O-RING | 2 | |
| 5P8112 | 47 GROMMET | 1 | |
| 5P9617 | 48 ADAPTER | 2 | |
| 5S7379 | 49 BOLT (3/8-16X0.875-IN) | 2 | |
| 6D4246 | 50 CLIP (LOOP) | 3 | |
| 6V5048 | 51 SEAL-O-RING | 3 | |
| 6V6782 | 52 CLIP (SLOT) | 1 | |
| 6V6783 | 53 CLIP (TAB) | 1 | |
| 7D7233 | 54 CLIP (LOOP) | 1 | |
| 7X0296 | 55 BOLT (3/8-16X5.5-IN) | 4 | |
| 8C3446 | 56 VALVE-SAMPLING | 3 | |
| 8L2779 | 57 SEAL-O-RING | 1 | |
| 8M2773 | 58 CLIP (LOOP) | 4 | |
| 8T4121 | 59 WASHER-HARD (11X21X2.5-MM THK) | 23 | |
| 8T4133 | 60 NUT (M10X1.5-THD) | 8 | |
| 8T4137 | 61 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4182 | 62 BOLT (M10X1.5X45-MM) | 8 | |
| 8T4184 | 63 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4223 | 64 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4896 | 65 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T5005 | 66 BOLT (M10X1.5X70-MM) | 2 | |
| 9S4181 | 67 PLUG (1-5/16-12-THD) | 1 |
