System And Components
468-4349 LINES GP-FUELS/N HRZ508-UP
Group No: 468-4349
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1358573 | 1 BOLT AS | 4 | |
| 1488317 | 2 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8714 | CONNECTOR | 1 | |
| 1488373 | 3 ELBOW AS | 2 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8C3364 | ELBOW | 1 | |
| 1594724 | 4 VALVE-BALL | 1 | |
| 1632426 | 5 VALVE-CHECK | 1 | |
| 1644058 | 6 REDUCER AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8948 | REDUCER | 1 | |
| 1984781 | 7 WASHER-HARD (22X40X10-MM THK) | 1 | |
| 2067013 | 8 FASTENER | 17 | |
| 2147568 | 9 SEAL-O-RING | 1 | |
| 2256948 | 10 SEAL-O-RING | 6 | |
| 2307636 | 11 HOSE AS | 1 | |
| 2451791 | 12 HOSE AS-AIR | 1 | |
| 3211326 | 13 BASE AS-FILTER | 3 | |
| 3232268 | STUD-HOLLOW | 1 | |
| 3293356 | 14 NUT (M12X1.75-THD) | 1 | |
| 3445675 | 15 NUT (M10X1.5-THD) | 3 | |
| 3574574 | 16 ADAPTER AS | 1 | |
| 8D8428 | ADAPTER | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3J1907 | 17 SEAL-O-RING | 2 | |
| 4224704 | 18 SPACER (10.5X20X60-MM THK) | 1 | |
| 4264093 | 19 ADAPTER AS | 2 | |
| 2385084 | SEAL-O-RING | 1 | |
| 4264092 | ADAPTER-TEE | 1 | |
| 4323700 | 20 CLAMP | 1 | |
| 4328132 | 21 CLAMP | 4 | |
| 4329428 | 22 CLAMP AS | 2 | |
| 8T9101 | BOLT (3/8-16X2.75-IN) | 2 | |
| 4345618 | NUT-SPECIAL | 2 | |
| 4329904 | 23 CLAMP AS | 2 | |
| 5S7383 | BOLT (3/8-16X1.75-IN) | 2 | |
| 4345618 | NUT-SPECIAL | 2 | |
| 4350692 | 24 PLATE-COVER | 2 | |
| 4357022 | 25 PLATE-COVER | 6 | |
| 4385386 | 26 FILTER AS-WATER SEP & FUEL (ULTRA HIGH EFFICIENCY) | 3 | |
| 4790856 | FILTER AS-WATER SEP & FUEL (ULTRA HIGH EFFICIENCY) | 3 | |
| 4391837 | 27 ELBOW AS | 1 | |
| 6V8991 | ELBOW | 1 | |
| 2287093 | SEAL-O-RING | 2 | |
| 4423312 | 28 ADAPTER | 1 | |
| 4423313 | 29 HOSE AS | 1 | |
| 4423321 | 30 CLAMP AS | 1 | |
| 4684351 | 31 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4687941 | 32 BRACKET AS | 2 | |
| 4689700 | 33 CLAMP-HALF | 4 | |
| 4689708 | 34 CLAMP-HALF | 8 | |
| 4779134 | 35 HOSE AS | 1 | |
| 4792171 | 36 BOLT AS | 16 | |
| 4S4455 | 37 CLIP | 2 | |
| 5115018 | 38 PUMP GP-FUEL | 1 | |
| 5689487 | 39 HOSE AS | 1 | |
| 5865347 | 40 HOSE AS | 1 | |
| 5865348 | 41 HOSE AS | 1 | |
| 5M3062 | 42 BOLT (3/8-16X0.75-IN) | 2 | |
| 5P7466 | 43 CLIP (SLOT) | 2 | |
| 5P7467 | 44 CLIP (TAB) | 2 | |
| 5P7468 | 45 CLIP (SLOT) | 2 | |
| 5P7469 | 46 CLIP (TAB) | 2 | |
| 5P7701 | 47 SEAL-O-RING | 2 | |
| 5P8112 | 48 GROMMET | 2 | |
| 5P8444 | 49 GROMMET (37-MM ID) | 2 | |
| 5P9617 | 50 ADAPTER | 2 | |
| 5S7379 | 51 BOLT (3/8-16X0.875-IN) | 2 | |
| 6D4246 | 52 CLIP (LOOP) | 3 | |
| 6V5048 | 53 SEAL-O-RING | 3 | |
| 6V6782 | 54 CLIP (SLOT) | 1 | |
| 6V6783 | 55 CLIP (TAB) | 1 | |
| 6V9172 | 56 NUT (1-7/16-12-THD) | 1 | |
| 7X2544 | 57 BOLT (M10X1.5X140-MM) | 4 | |
| 8C3446 | 58 VALVE-SAMPLING | 3 | |
| 4640509 | 59 SEAL-O-RING | 1 | |
| 8M2773 | 60 CLIP (LOOP) | 4 | |
| 8T4121 | 61 WASHER-HARD (11X21X2.5-MM THK) | 40 | |
| 8T4133 | 62 NUT (M10X1.5-THD) | 8 | |
| 8T4172 | 63 BOLT (M10X1.5X80-MM) | 8 | |
| 8T4182 | 64 BOLT (M10X1.5X45-MM) | 12 | |
| 8T4184 | 65 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4198 | 66 BOLT (M10X1.5X100-MM) | 1 | |
| 8T4223 | 67 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4896 | 68 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T5005 | 69 BOLT (M10X1.5X70-MM) | 2 | |
| 8W5161 | 70 MANIFOLD | 1 | |
| 9S4181 | 71 PLUG (1-5/16-12-THD) | 1 |
